Product Overview
When industrial networks require reliable bridging between Modicon platforms, the Schneider NWBP85002 Modbus Plus Bridge delivers seamless connectivity. This industrial automation module is engineered for use in both Premium and Quantum systems, ensuring efficient data exchange across automation networks.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Type |
Modbus Plus Bridge |
| Product Line |
Modicon |
| Part Number |
NWBP85002 |
| Weight |
4.00 lbs (1.81 kg) |
| Application |
Communication assembly for Modicon platforms |
| Rated Supply Voltage |
115...220 V AC, 24 V DC |
| Port Configuration |
4 communication ports |
| Accessory Type |
Connection accessory |
| Protocol Supported |
Modbus Plus |
| Compatibility |
Modicon Premium/Quantum automation platforms |
| Panel Mounting |
Supported |
| Shelf Mounting |
Supported |
Compatibility and Integration
The Schneider NWBP85002 is designed to integrate with Modicon Premium and Quantum automation platforms. Its four communication ports allow connection to multiple devices over the Modbus Plus protocol, simplifying network topology and reducing wiring complexity. This bridge acts as a central node for data exchange, making it ideal for upgrading older systems or expanding existing networks.
Installation and Setup Guidance
Mounting the NWBP85002 is straightforward. The module supports both panel and shelf mounting, providing flexibility for cabinet or rack installations. Ensure the supply voltage matches one of the specified ranges: 115–220 V AC or 24 V DC. Connect the Modbus Plus cables to the four ports, verifying termination settings per network requirements. The compact design fits easily into existing enclosures without major reconfiguration.
Selection Guide and Purchasing Advice
Before purchasing the Schneider NWBP85002, verify compatibility with your Modicon system generation (Premium or Quantum). This bridge is a direct replacement for older Modbus Plus bridges and enhances performance with its multi-port design. For reliable sourcing, choose industrial automation suppliers like ubest101 to ensure genuine parts and timely delivery. Check environmental conditions (industrial network environments) to confirm suitability.
