Product Introduction
The Schneider BMXFTB2010 is a high-quality 20-pin removable screw clamp terminal block designed for use with Modicon X80 automation modules. As a genuine Schneider Electric accessory, the BMXFTB2010 ensures secure and reliable connections in industrial control systems. This terminal block is ideal for applications requiring up to 20 connections, supporting wire sizes from 1 to 2 x 0.34..1.5 mm². Whether you are upgrading an existing system or replacing a worn component, the BMXFTB2010 provides a straightforward replacement path.
Technical Specifications
While detailed technical specifications are not available, the BMXFTB2010 offers the following confirmed parameters from the product documentation:
-
Number of terminals: 20 removable screw clamp terminal block
-
Wire size: 1 or 2 x 0.34..1.5 mm²
-
Product range: Modicon X80
-
Net weight: 0.075 kg
-
Package 1 dimensions: 3.600 cm x 4.600 cm x 11.000 cm (H x W x L)
-
Package 1 weight: 95.000 g
-
EU RoHS compliant: Pro-active compliance (product out of EU RoHS legal scope)
-
Toxic heavy metal free: Yes
-
Mercury free: Yes
For additional technical parameters, please contact PLC Source PRO directly.
Installation & Setup Guide
Installing the Schneider BMXFTB2010 is straightforward. Follow these steps for a secure connection:
- Ensure the module is disconnected from power before installation.
- Align the BMXFTB2010 with the 20-pin connector on the Modicon X80 module.
- Firmly push the terminal block into place until it clicks or is fully seated.
- Use a screwdriver to tighten the clamp screws for each wire. Recommended torque is within standard industrial practice.
- Verify that each wire is securely clamped and that no loose strands are exposed.
For optimal performance, use the specified wire sizes (1 or 2 x 0.34..1.5 mm²). Avoid over-tightening which may damage the terminal.
Compatibility & Integration
The Schneider BMXFTB2010 is designed exclusively for Modicon X80 modules that feature a 20-pin removable terminal block interface. It is compatible with a wide range of input, output, and mixed modules within the Modicon X80 family. This terminal block acts as a reliable interface between field wiring and the controller, simplifying both initial installation and future maintenance. When replacing older terminal blocks, the BMXFTB2010 offers a drop-in replacement that maintains system integrity.
Selection Guide & Purchasing Advice
When selecting the BMXFTB2010, verify that your existing module uses a 20-pin screw clamp terminal block configuration. This accessory is a standard component for Modicon X80 systems and is readily available from trusted suppliers. At PLC Source PRO (formerly ubest101), we stock genuine Schneider BMXFTB2010 terminal blocks to ensure reliable delivery for your automation projects. For quantity discounts or urgent orders, please reach out to our sales team.
