Product Overview
In complex industrial automation systems, the Schneider BMEP584020 delivers robust processing power and comprehensive cybersecurity to ensure reliable control. This standalone processor from the Modicon M580 series supports up to 125 Ethernet devices and manages 8 local I/O racks with 4096 digital and 1024 analog I/O. With 16MB of program memory and advanced communication features, the Schneider BMEP584020 is engineered for demanding applications.
Technical Specifications
| Parameter |
Value |
| Number of racks |
8 |
| Local I/O (discrete) |
4096 I/O |
| Local I/O (analog) |
1024 I/O |
| Program memory (RAM) |
16 MB |
| Data memory (RAM) |
2048 kB |
| System memory (RAM) |
10 kB |
| Expandable flash storage |
4 GB |
| Integrated Ethernet ports |
1 service port, 2 device network |
| Distributed equipment support |
128 |
| Communication modules |
8 AS-Interface, 4 Ethernet |
| Cybersecurity |
Achilles certified, IPSec, TLS, firewall |
| Current consumption |
295 mA at 24 V DC |
| MTBF reliability |
775,000 hours |
| Operating temperature |
32…140 °F (0…60 °C) |
| Vibration resistance |
3 gn |
| Shock resistance |
30 gn |
| IP protection |
IP20 |
| Net weight |
1.872 lb (0.849 kg) |
Industry Applications
The Schneider BMEP584020 excels in process control, motion control, and HART-based instrumentation. Its high MTBF of 775,000 hours minimizes downtime, offering exceptional ROI for manufacturing plants, water treatment facilities, and energy management systems. The processor handles 144 application-specific channels per local rack, enabling precise control and data acquisition.
Compatibility & Integration
As part of the Modicon M580 family, the Schneider BMEP584020 integrates seamlessly with Ethernet TCP/IP networks, supporting distributed I/O, AS-Interface modules, and third-party devices. It communicates via USB mini B for local programming and includes two dedicated Ethernet device network ports. The processor also supports cybersecurity features like IPSec, SNMP logging, and syslog protocol for secure operations.
Maintenance & Reliability
Designed for harsh environments, the Schneider BMEP584020 withstands vibration up to 3 gn and shock up to 30 gn. It operates from 0 to 60 °C and is rated for hazardous locations (Class I Division 2). Status LEDs provide real-time diagnostics for RUN, ERR, I/O faults, and communication status, simplifying troubleshooting and reducing maintenance time.
Selection Guide & Purchasing Advice
Before purchasing the Schneider BMEP584020, verify internal power supply compatibility via your rack system and confirm required firmware version. The unit ships in a compact package (9.84 x 7.09 x 3.54 inches) weighing 1.872 lb. For reliable sourcing of genuine automation modules, trust PLC Source PRO at ubest101 – your partner for industrial control spares.
