Product Overview
The Schneider BMENOS0300C is a switch module designed for the Modicon X80 range. This industrial automation module provides reliable Ethernet/IP connectivity for device networks and service ports, ensuring robust communication in demanding control systems.
Technical Specifications
-
Rated Supply Voltage: 24 V for back plane
-
Power Consumption: 3.3 W at 135 mA (25 °C); 4.5 W at 185 mA (60 °C)
-
Ports: 3 integrated connections
-
Connection Type: Ethernet/IP for device network and service port
-
Protocol: EtherNet/IP
-
Local Signaling: LEDs for RUN (green), ERR (red), Module Status (green/red), Network Status (green/red)
-
Dimensions (Package 1): 5.800 x 11.200 x 12.200 cm; Weight 264.000 g
Real-World Applications
The Schneider BMENOS0300C excels in applications requiring high network reliability. In oil and gas environments, its gas-resistant and dust-resistant properties (Class Gx per ISA S71.04, Class 3C4 per IEC 60721-3-3) prevent failure due to corrosive gases and particulates. For power substations, the module’s compliance with EN/IEC 61850-3 ensures stable operation under electromagnetic interference. The conformal coating protects against moisture and chemical exposure, reducing downtime in manufacturing lines with high humidity up to 95% non-condensing.
Compatibility and Integration
The Schneider BMENOS0300C is fully compatible with BMEXBP... backplanes in the Modicon X80 system. It integrates seamlessly into existing EtherNet/IP networks, supporting both device-level and service port communications. The module’s standard format allows direct mounting in X80 racks without additional adapters.
Maintenance and Reliability
Designed for harsh environments, the Schneider BMENOS0300C operates reliably from 0 to 60 °C and can be stored from -40 to 85 °C. Its IP20 protection and conformal coating minimize dust and moisture ingress. Periodic inspection of LEDs provides quick status checks: green RUN indicates normal operation, red ERR signals faults, and the Module/Network Status LEDs change color to indicate communication health. For maximum lifespan, ensure ventilation around the module to avoid exceeding 60 °C ambient temperature.
Selection Guide and Purchasing Advice
Before purchasing the Schneider BMENOS0300C, verify your backplane model (BMEXBP... series) and confirm that your network infrastructure supports EtherNet/IP. The module comes as a single unit in Package 1 and is available in multi-packs (5 units) for larger projects. For a reliable supplier, consider purchasing from ubest101, which offers authentic, inspected modules for industrial automation needs.
