Product Introduction
The Schneider BMENOP0300C is a communication module from the Modicon M580 series, designed to serve as a high-performance gateway for programmable automation controllers (PACs). When legacy systems require modernization to support IEC 61850 substation automation or to reduce network complexity, the BMENOP0300C provides a seamless upgrade path. It integrates three Ethernet 10/100BASE-TX ports and supports MMS messaging, GOOSE, and Modbus TCP, making it ideal for migrating from older fieldbus architectures to a fully digital, IP-based control network.
Technical Specifications Breakdown
The Schneider BMENOP0300C operates with a 3.3 V DC internal current consumption of 1250 mA. It supports dual transmission rates of 10 Mbit/s and 100 Mbit/s over standard Ethernet cable. The module complies with multiple international standards including EN/IEC 61131-2, EN/IEC 61010-2-201, and UL 61010-2-201, ensuring reliable performance in industrial environments. Its conformal coating protects against moisture and contaminants, while the -40 to 185 °F storage temperature range allows for robust long-term storage. The unit weighs 0.24 kg (0.53 lb) and measures 5.500 cm x 11.100 cm x 11.600 cm in its primary package.
Industry Applications
In electrical substations, the Schneider BMENOP0300C facilitates IEC 61850 MMS and GOOSE communications, enabling faster protection schemes and reduced copper wiring. For manufacturing facilities with Modicon M580 PACs, it provides direct Modbus TCP connectivity, simplifying integration with existing SCADA systems. When upgrading from older communication modules, the BMENOP0300C eliminates the need for protocol converters, lowering total cost of ownership.
Compatibility & Integration
The Schneider BMENOP0300C is fully compatible with Modicon M580 PACs. It supports IEC 61850 communication services (MMS client/server, GOOSE), Modbus TCP messaging, RSTP for network redundancy, and IP forwarding. The module is certified for CE, UL, CSA, RCM, EAC, ATEX Zone 2/22, and IECEx Zone 2/22, making it suitable for hazardous locations. It also meets environmental class Gx (ISA S71.04), 3C4 (IEC 60721-3-3), and salt spray level 2 (IEC 68252).
Installation & Setup Guidance
Mount the Schneider BMENOP0300C in a standard slot of the M580 rack using the module format. Connect Ethernet cables to the three RJ45 ports (10/100BASE-TX). Confirm that the PAC firmware supports the module. For IEC 61850 networks, configure the MMS and GOOSE parameters in the engineering tool. The module automatically negotiates transmission speed; for fixed 100 Mbit/s operation, use Category 5e or better cable. No external power supply is needed— the module draws power from the backplane.
Selection Guide & Purchasing Advice
Before purchasing the Schneider BMENOP0300C, verify that your PAC chassis has an available slot and that the backplane current capacity exceeds 1250 mA at 3.3 V. Ensure your network infrastructure supports 10/100BASE-TX. For applications requiring IEC 61850 compliance, confirm that your substation automation system is compatible with MMS and GOOSE. As a reliable distributor, ubest101 offers genuine BMENOP0300C modules with fast shipping. Check the GTIN (3606481285997) to confirm authenticity.
Frequently Asked Questions
What is the exact power requirement for the BMENOP0300C?
The module consumes 1250 mA at 3.3 V DC supplied from the Modicon M580 backplane. No additional external power is required.
Can the BMENOP0300C replace an older Ethernet module?
Yes, the BMENOP0300C is designed as a drop-in upgrade for M580 PAC systems. It adds IEC 61850 capability while maintaining backward compatibility with Modbus TCP.
Does this module support network redundancy?
Yes, the BMENOP0300C supports RSTP (Rapid Spanning Tree Protocol) for ring or redundant Ethernet topologies.
What certifications does the BMENOP0300C hold?
It is certified for CE, UL, CSA, RCM, EAC, ATEX Zone 2/22, and IECEx Zone 2/22. It also complies with EN/IEC 61850-3 and IEEE 1613 for substation environments.
