Product Introduction
The Schneider BMENOC0321C is a high-performance Modicon M580 communication module designed for demanding industrial automation networks. As part of the Modicon M580 range, the BMENOC0321C replaces older communication processors with enhanced speed and reliability. This module provides three Gigabit Ethernet RJ45 ports (10/100/1000 Mbps) with double-shielded twisted-pair connections, enabling robust data exchange in Ethernet backplane architectures. Ideal for system upgrades, the BMENOC0321C integrates seamlessly into BMEXBP racks, supporting both advanced web server functions and a broad set of communication services.
Technical Specifications Breakdown
The BMENOC0321C delivers key performance characteristics essential for modern control systems:
-
Current Consumption: 1800 mA at 3.3 V DC – reliable internal power supply via rack
-
Integrated Connection: 3 Ethernet RJ45 ports with auto-negotiation (10/100/1000 Mbps)
-
Protocol Support: Modbus TCP I/O Scanner and Messaging, EtherNet/IP I/O Scanner and Messaging, RSTP, IP forwarding, FDR server, bandwidth management, email, and web services (FactoryCast configurable)
-
Memory Usage: Application saving and advanced web server activation
-
Indicators: Six LEDs for RUN, ERR, and Ethernet status (MS, NS, NS1, NS2)
-
Protection: IP20, conformal coating, wide operating temperature 32…140 °F (0…60 °C)
These specs ensure the BMENOC0321C handles demanding control and monitoring tasks while maintaining high uptime in harsh industrial environments.
Industry Applications
The Schneider BMENOC0321C excels in upgrading legacy Modicon systems to the latest M580 architecture. Typical applications include:
-
Process Control: In chemical plants and refineries, the BMENOC0321C provides deterministic Modbus TCP communication for critical loops and safety interlocks.
-
Discrete Manufacturing: Automakers use this module for high-speed EtherNet/IP I/O scanning in assembly lines, reducing cycle times.
-
Utility Substations: With certifications like IEC 61850-3 and ATEX Zone 2/22, the BMENOC0321C is suitable for power distribution and hazardous area monitoring.
Compatibility & Integration
The BMENOC0321C is designed for Modicon M580 racks – specifically the BMEXBP series (Ethernet + X-bus). It replaces older communication modules without requiring full system redesign. Integration is straightforward: simply insert the module into any available slot, supply power via the rack backplane, and configure the communication services using Unity Pro or Control Expert. The module supports FDR server for easy device replacement, RSTP for network redundancy, and both Modbus TCP and EtherNet/IP for multi-vendor interoperability. Ensure your firmware version matches your host controller for optimal performance.
Selection Guide & Purchasing Advice
When ordering the Schneider BMENOC0321C, verify that your rack model is BMEXBP… and that your control software supports M580 architecture. The module ships in a single unit package (PCE) weighing 0.4 lb (0.2 kg). For bulk orders, note that the outer carton (S02) holds 15 units. PLC Source PRO (available at ubest101) stocks genuine, factory-sealed BMENOC0321C modules with full traceability and warranty. Always confirm part number BMENOC0321C to ensure you receive the correct variant for your automation upgrade.
