Product Overview
The Schneider BMENOC0311C is a high-performance communication module from the Modicon M580 range designed for demanding industrial automation environments. It integrates seamlessly into BMEXBP Ethernet + X-bus racks, providing robust data exchange and network management capabilities. This module supports multiple communication protocols including Modbus TCP and Ethernet/IP I/O Scanner, making it an essential component for modern distributed control systems (DCS) and plant-wide networking.
Technical Specifications
| Parameter |
Value |
| Supply |
Internal power supply via rack |
| Current consumption (≥ V13) |
900 mA at 3.3 V DC |
| Current consumption (< V13) |
1800 mA at 3.3 V DC |
| Integrated connections |
3 x RJ45 Ethernet, 10/100 Mbit/s |
| Communication services |
Bandwidth management, FDR server, SNMP, Modbus TCP I/O Scanner & Messaging, Ethernet/IP I/O Scanner & Messaging, RSTP, port mirroring, embedded multiport switch |
| LED indicators |
RUN (green), ERR (red), ETH MS (green/red), Eth NS (green/red) |
| Weight |
0.2 kg |
| IP protection |
IP20 |
| Operating temperature |
0…60 °C |
| Certifications |
CE, UL, CSA, RCM, EAC, ATEX zone 2/22, IECEx zone 2/22 |
Field Applications
The Schneider BMENOC0311C excels in applications requiring deterministic control over Ethernet networks. Typical use cases include manufacturing cell control, material handling systems, and process automation where low-latency I/O scanning and redundant network topologies (RSTP) are critical. Its dual-protocol support allows seamless integration with existing Modbus TCP or Ethernet/IP based systems, reducing migration costs and preserving capital investments.
Integration & Compatibility
Designed for the Modicon M580 ecosystem, the BMENOC0311C works exclusively with BMEXBP racks that combine Ethernet and X-bus backplane. It supports advanced network services such as SNMP network administration and FactoryCast configurable web server, enabling remote monitoring and diagnostics. The embedded multiport switch simplifies wiring, while port mirroring aids in troubleshooting without disrupting live traffic.
Selection Guide & Purchasing Advice
When ordering the Schneider BMENOC0311C, verify that your rack model is BMEXBP series (Ethernet + X-bus). Also confirm the firmware version (≥ V13) to ensure optimal current consumption of 900 mA. For bulk requirements, package 2 contains 15 units. PLC Source PRO (formerly ubest101) stocks genuine modules with full warranty – contact us for volume discounts or expedited shipping options.
