Product Overview
When communication failures disrupt your production line, the Schneider BMECXM0100H provides reliable connectivity for demanding industrial environments. This CANopen communication module, part of the Modicon X80 range, ensures stable data exchange between controllers and field devices. Designed for the M580 PLC, the BMECXM0100H uses an open industrial fieldbus structure with NRZ transmission and a DB9 connector, making it ideal for applications requiring high noise immunity and long-distance communication.
Choose the Schneider BMECXM0100H to eliminate common communication dropouts and maintain uptime in harsh conditions.
Technical Specifications
| Parameter |
Value |
| Product Range |
Modicon X80 |
| Type |
CANopen communication module |
| Structure Type |
Open industrial fieldbus |
| Product Compatibility |
M580 PLC |
| Physical Interface |
DB9 female connector |
| Transmission Support Medium |
Profibus DP twisted shielded pairs cable |
| Transmission Rates (Distance) |
9.6 kbit/s (1200 m), 19.2 kbit/s (1200 m), 93.75 kbit/s (1200 m), 187.5 kbit/s (1000 m), 500 kbit/s (400 m), 1.5 Mbit/s (200 m), 3 Mbit/s (100 m), 12 Mbit/s (100 m) |
| Number of Server Devices |
63 |
| Communication Service |
Implicit exchange of process data (20…70 °C) |
| Rated Supply Voltage |
24 V DC internal |
| Current Consumption |
70 mA |
| Module Format |
Standard |
| Operating Temperature |
-25…70 °C |
| Storage Temperature |
-45…85 °C |
| Relative Humidity |
10…95 % |
| Operating Altitude |
≤ 2000 m |
| Protective Treatment |
Conformal coating |
| Product Certifications |
CE, UL, CSA, RCM, EAC, Merchant Navy, ATEX zone 2/22, IECEx zone 2/22 |
| Standards |
EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201, IACS E10, EN/IEC 61000-6-5, EN/IEC 61850-3, EN/IEC 60079-0 |
| Environmental Characteristics |
Gas resistant (Gx ISA S71.04, 3C4 IEC 60721-3-3), Dust/Sand resistant (3S4), Salt resistant (level 2), Mold/Fungal spore resistant (3B2), Hazardous location Class I Division 2 |
Real-World Applications
The Schneider BMECXM0100H excels in environments where communication reliability is critical. For example, in a wastewater treatment plant, the module connects remote I/O stations to an M580 controller over long distances using 93.75 kbit/s transmission up to 1200 m, ensuring consistent process data exchange even in humid, corrosive atmospheres. In automotive assembly lines, the BMECXM0100H’s multiple baud rates allow flexible network speeds, while its ATEX and IECEx certifications enable safe operation in Zone 2/22 hazardous areas.
Another typical use is in power distribution systems, where the module’s conformal coating and gas resistance protect against sulfur and chlorine contaminants, preventing communication failures and reducing downtime.
Compatibility & Integration
The Schneider BMECXM0100H integrates seamlessly with the Modicon X80 backplane and is fully compatible with M580 PLCs. It supports Profibus DP twisted shielded pairs cable via a single SUB-D 9-pin female connector. The module uses CANopen protocol with NRZ encoding, allowing direct connection to field devices like drives, sensors, and actuators. Multiple BMECXM0100H units can be used to create a star or daisy-chain topology, managing up to 63 server devices.
For integration into existing systems, the module follows EN/IEC 61131-2 and UL 61010-2-201 standards, ensuring interoperability with other automation components. The provided communication service includes implicit exchange of process data within the specified temperature range.
Selection Guide & Purchasing Advice
Before purchasing the Schneider BMECXM0100H, verify that your PLC is an M580 and that the backplane has an available slot for a standard format module. Ensure that the network cable is Profibus DP twisted shielded pairs with appropriate length for your baud rate (e.g., for 12 Mbit/s, maximum cable length is 100 m). No additional accessories are required for basic operation, but consider using a terminating resistor if the module is at the end of a network segment.
For reliable sourcing and fast delivery, trust PLC Source PRO (available through ubest101). As your industrial automation parts supplier, we stock genuine Schneider modules with full traceability. Contact us for additional support on configuration or system design.
