The Schneider BMECXM0100 is a dedicated CANopen communication module designed for the Modicon X80 automation platform. As part of Schneider's Industrial Automation Module lineup, the BMECXM0100 enables robust, open-fieldbus connectivity for M580 PLC systems. This module is engineered to enhance system reliability and reduce downtime through its robust design.
Technical Specifications
The Schneider BMECXM0100 operates on a 24 V DC internal supply and draws only 100 mA. It supports variable transmission rates for flexible network topology, from 20 kbit/s over 2500 m with a repeater to 1 Mbit/s over 20 m without a repeater. The module uses a DB9 connector and communicates via CSMA/CA CANopen with NRZ transmission mode over twisted shielded pairs.
| Parameter |
Value |
| Product Compatibility |
M580 PLC |
| Transmission Rate |
20 kbit/s – 1 Mbit/s |
| Number of Server Devices |
63 |
| Communication Service |
CiA DSP 301 V4.02 |
| Supply Voltage |
24 V DC internal |
| Current Consumption |
100 mA |
| Operating Temperature |
0…60 °C |
| Storage Temperature |
-45…85 °C |
| Relative Humidity |
10…95 % without condensation |
| Altitude |
≤ 2000 m |
Industry Applications
The Schneider BMECXM0100 excels in applications requiring high-speed data exchange across multiple slave devices, such as packaging lines, material handling, and process control. Its ability to support up to 63 servers and adapt to various transmission speeds makes it ideal for upgrading legacy CANopen networks. By integrating the BMECXM0100, manufacturers achieve higher throughput and reduced operational costs.
Maintenance & Reliability
The BMECXM0100 is built to operate reliably in harsh industrial environments, with an ambient temperature range of 0 to 60 °C and humidity up to 95% without condensation. Regular inspection of the DB9 connector and CANopen cable integrity helps maintain signal quality. The module's low current consumption (100 mA) reduces thermal stress, extending service life and lowering total cost of ownership.
Compatibility & Integration
Designed for the Modicon X80 range, the Schneider BMECXM0100 integrates seamlessly with M580 PLCs. It uses standard CANopen twisted shielded pairs and supports repeaters for extended distances. The open industrial fieldbus structure allows easy connection to existing CANopen devices without additional gateways.
Selection Guide & Purchasing Advice
When selecting the BMECXM0100, verify that your system uses a 24 V DC supply and that the DB9 connector is accessible. For long-distance installations, plan for repeaters as needed. PLC Source PRO offers genuine Schneider BMECXM0100 modules with fast shipping. Contact ubest101 for bulk pricing or technical support.
