Cost-Effective Motor Control with the ATV61HU40N4
The Schneider ATV61HU40N4 Variable Speed Drive delivers reliable performance and energy savings for industrial motor applications. Part of the Altivar 61 series, this drive integrates an EMC filter to reduce electromagnetic interference, minimizing downtime and maintenance costs. With a power rating of 4 kW (5 HP) and support for 380-480 V 3-phase supply, the ATV61HU40N4 is built for demanding environments.
Technical Specifications
| Parameter |
Value |
| Product Type |
Variable Speed Drive |
| Product Line |
Altivar 61 |
| Part Number |
ATV61HU40N4 |
| Supply Voltage |
380-480 V, 3-phase |
| Power Rating |
4 kW / 5 HP |
| Line Current |
5.4 A |
| Apparent Power |
5.5 kVA |
| Nominal Switching Frequency |
12 kHz |
| Switching Frequency Range |
1-16 kHz adjustable |
| EMC Filter |
Integrated |
| Protection Rating |
IP20 |
| Maximum Transient Current |
7.5 A (60 seconds) |
| Supply Frequency |
50/60 Hz |
| Assembly Style |
With heat sink |
| Weight |
25.00 lbs (11.34 kg) |
Industry Applications for Long-Term Value
The Schneider ATV61HU40N4 excels in pump, fan, and conveyor applications where adjustable speed reduces energy consumption. For example, in HVAC systems, the integrated EMC filter ensures compliance with electromagnetic standards, preventing costly interference issues. The 1-16 kHz adjustable switching frequency allows tuning for motor noise reduction, extending equipment life.
Maintenance and Reliability
Routine inspection of the heat sink and cooling fans keeps the ATV61HU40N4 operating efficiently. The IP20 enclosure protects against dust and accidental contact, suitable for clean indoor environments. The integrated EMC filter reduces the risk of drive faults from electrical noise, lowering unscheduled downtime and repair costs.
Selection Guide and Purchasing Advice
When selecting the Schneider ATV61HU40N4, verify that your motor's full-load current does not exceed 5.4 A and that the supply voltage matches 380-480 V 3-phase. For reliable sourcing and expert support, contact PLC Source PRO (store: ubest101.myshopify.com) to confirm compatibility and ensure prompt delivery.
