Product Introduction
With specs like 8 discrete input points at 115 VAC, the Schneider AS-BDEP-211 handles demanding industrial sensing tasks. Part of the Modicon family, this I/O module is engineered for reliable discrete input acquisition. It requires minimal internal power (<35mA at 5V) while delivering consistent performance across automated environments.
Technical Specifications Breakdown
The Schneider AS-BDEP-211 offers the following key parameters:
-
Input Points: 8 discrete inputs for monitoring switches, sensors, and limit devices.
-
Voltage Range: 115 VAC ensures compatibility with standard AC field wiring.
-
Points per Common: 1 — each input operates independently.
-
Internal Power: <35mA at 5V — low burden on the backplane supply.
-
Addressing I/O Bits: 8/0 — dedicated input bits with no output allocation.
With a weight of 0.81 lbs (0.37 kg), the module is compact and easy to handle during installation.
Industry Applications
The AS-BDEP-211 excels in manufacturing lines, packaging machinery, and conveyor systems. Its 115 VAC discrete inputs are ideal for interfacing with legacy AC sensors and pushbuttons. In a typical application, it reads limit switch states to control motor start/stop sequences. This reduces I/O wiring complexity and improves system reliability.
Compatibility & Integration
Designed for the Modicon series, the Schneider AS-BDEP-211 integrates seamlessly with Modicon PLCs and remote I/O racks. It uses standard backplane communication and fits the same form factor as other Modicon modules. When planning a system expansion, verify addressing 8/0 bits are available in your PLC configuration.
Selection Guide & Purchasing Advice
Before purchasing the AS-BDEP-211, confirm your system supports 115 VAC discrete input modules and that available slots match the module’s width. Ensure your power supply can handle the <35mA at 5V draw. For a genuine, tested unit, contact ubest101 at their store ubest101.myshopify.com — a trusted supplier of industrial automation spares.
