Product Introduction
When panel space and system reliability are critical, the Schneider AS-BDEP-210 discrete input module offers a compact, isolated solution for 120 VAC input sensing. Designed for the Modicon product line, this module provides 8 input points, making it an ideal building block for various industrial control tasks. Its compact build reduces cabinet footprint, leading to cost savings in enclosure and installation.
Technical Specifications
The following specifications apply to the Schneider AS-BDEP-210 discrete input module.
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon |
| Part Number |
AS-BDEP-210 |
| Weight |
0.63 lbs (0.28 kg) |
| Product Type |
Discrete Input Module |
| Number of Input Points |
8 |
| Input Voltage |
120 VAC |
| Input Frequency |
50/60 Hz |
| Isolated |
Yes |
| Build |
Compact |
Industry Applications
The Schneider AS-BDEP-210 is well-suited for automation tasks such as monitoring limit switches, push buttons, and sensor signals in manufacturing lines. For example, in a conveyor sorting system, the module's dedicated 8 inputs can reliably detect product presence, while its isolation prevents ground loops from corrupting signals. The compact size allows for dense I/O placement, lowering overall system cost per point. In packaging machines, the AS-BDEP-210's 120 VAC compatibility integrates directly with existing control voltage, eliminating the need for additional conversion.
Installation & Setup Guidance
Mount the Schneider AS-BDEP-210 in a clean, dry environment within a suitable enclosure. Ensure that the backplane or bus connector is properly engaged with the Modicon rack. Wire each input to a 120 VAC source and common using appropriate gauge wire for the current draw. Apply power only after confirming voltage and frequency match the module's rating (50/60 Hz). The compact build simplifies placement in dense cabinets, but maintain adequate airflow around the module for passive cooling.
Maintenance & Reliability
The Schneider AS-BDEP-210's isolated inputs protect against transient interference, reducing false triggering and associated downtime. Regularly inspect wiring connections for tightness and signs of corrosion. Given the module's solid-state design, it requires minimal maintenance. Periodic cleaning of the enclosure filters and confirming ambient temperature remains within unspecified but reasonable industrial limits will extend service life. This reliability translates directly into lower total cost of ownership.
Selection Guide & Purchasing Advice
Before ordering, verify that the Schneider AS-BDEP-210 matches your Modicon system's backplane type and that your application requires 8 discrete 120 VAC inputs. Ensure your controller supports 50/60 Hz operation. For large installations, ordering spares from PLC Source PRO (available on ubest101.myshopify.com) ensures consistent performance across your facility. Always confirm part number and condition with the supplier to guarantee compatibility.
