Product Introduction
Upgrading your legacy output system? The Schneider AS-BDAP-210 Industrial Automation Module provides a modern, efficient solution. Part of the Modicon series, this output module delivers 8-point AC output with a wide voltage range from 24V AC to 240V AC. Each point supports up to 1A, totaling 8A per module, making it ideal for replacing older discrete output modules in industrial control systems.
Technical Specifications Breakdown
The Schneider AS-BDAP-210 offers robust specifications designed for demanding environments. Below are the key parameters:
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon |
| Part Number |
AS-BDAP-210 |
| Weight |
0.69 lbs (0.31 kg) |
| Height |
1.77 in (4.5 cm) |
| Width |
6.50 in (16.5 cm) |
| Length |
8.07 in (20.5 cm) |
| Functionality |
8-point AC output |
| Output Type |
Digital AC Output |
| Output Voltage Range |
24V AC to 240V AC |
| Output Current per Point |
1 A maximum |
| Output Current per Module |
8 A |
| Isolation |
Electrical isolation |
| Operating Temperature Range |
-20°C to 60°C |
| Power Consumption |
3 W |
| Bus Communication |
Modbus |
| Mounting |
DIN rail mounting |
The wide output voltage range and modular current capability make the Schneider AS-BDAP-210 versatile for various applications. Electrical isolation enhances safety, while Modbus communication ensures seamless integration into existing networks.
Industry Applications
The Schneider AS-BDAP-210 excels in applications such as controlling solenoid valves in batch processing, driving motor starters for conveyors, and managing lighting in industrial facilities. Its Modbus communication allows for direct replacement of older modules while improving system diagnostics and control.
Installation & Setup Guidance
Mount the Schneider AS-BDAP-210 on a standard DIN rail. Ensure proper alignment and secure the module with the mounting latch. Connect the AC supply to the voltage range indicated (24V to 240V AC). Use appropriate wiring gauges for 1A per point. The electrical isolation requires careful grounding practices to prevent ground loops.
Compatibility & Integration
The Modbus communication protocol of the Schneider AS-BDAP-210 enables integration with Schneider Modicon controllers and third-party devices. It works seamlessly with systems that support Modbus RTU. This module is an ideal upgrade for older output modules lacking digital communication.
Selection Guide & Purchasing Advice
Before purchasing, verify that your system requires an 8-point AC output with a voltage range of 24V to 240V AC and current needs up to 8A total. Ensure the bus interface is Modbus-compatible. When ordering, rely on ubest101 for genuine Schneider parts. The AS-BDAP-210 is a reliable choice for modernizing your control system.
