Product Overview
The Schneider AS-B875-001 is an analog compact input module designed for Schneider Electric's Modicon Quantum series. This industrial automation module handles data acquisition tasks efficiently, supporting up to eight inputs with a current range of 4 to 20 mA and a voltage range of 1 to 5 V. Ideal for upgrading existing systems or replacing older modules, the AS-B875-001 ensures reliable performance in clean indoor environments.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon Quantum |
| Part Number |
AS-B875-001 |
| Weight |
4.00 lbs (1.81 kg) |
| Product Type |
Compact Input Module |
| Analog Module |
Yes |
| Current Range |
4 to 20 mA |
| Number of Inputs |
8 Inputs |
| Voltage Range |
1 to 5 V |
| Operating Temperature |
0 to 40 °C |
| Maximum Operating Humidity |
80% RH (non-condensing) |
| Storage Temperature |
0 to 50 °C |
| Maximum Storage Humidity |
80% RH (non-condensing) |
| Maximum Operating Altitude |
1000 m above sea level |
| Maximum Storage Altitude |
1000 m above sea level |
| Environment |
Clean indoor, no corrosive chemicals |
Industry Applications
The Schneider AS-B875-001 excels in process control applications requiring precise analog signal acquisition. Typical uses include monitoring sensors in manufacturing lines, controlling temperature or pressure loops, and data logging in industrial automation systems. Its 4-20 mA current input compatibility makes it suitable for long-distance signal transmission without significant loss. As part of the Modicon Quantum family, the AS-B875-001 integrates seamlessly into existing Schneider control architectures, enabling straightforward upgrades for improved reliability.
Installation and Setup
Mount the Schneider AS-B875-001 module in a compatible Modicon Quantum backplane. Ensure the environment is clean and free from corrosive chemicals, with operating temperature between 0 and 40 °C and humidity not exceeding 80% RH without condensation. Connect 4-20 mA or 1-5 V signals to the appropriate input terminals. No special calibration is required for standard use. Verify that the module's altitude rating (1000 m maximum) meets your site conditions.
Maintenance and Reliability
The AS-B875-001 requires minimal routine care. Periodically inspect connections for corrosion or loosening, and ensure the enclosure maintains proper airflow to stay within the 0-40 °C range. When stored, keep within 0-50 °C and 80% RH without condensation. This module's robust design for clean indoor environments reduces the likelihood of failure, contributing to lower total cost of ownership and extended service life.
Selection Guide and Purchasing Advice
Before purchasing the Schneider AS-B875-001, verify compatibility with your Modicon Quantum system and confirm that your application requires 8 analog inputs with 4-20 mA or 1-5 V signals. For genuine, tested modules, rely on trusted suppliers like ubest101. Ensure you have the correct backplane and power supply for installation. This module is a direct replacement for legacy compact input modules, offering the same form factor and enhanced specification adherence.
