In Modicon Quantum analog I/O applications, the Schneider ABFS08H202 delivers precise signal connectivity. This 2-meter cable module uses an HE-08 connector and eight AWG 22 conductors for reliable data transmission. Its plug-and-play design minimizes installation time, making it a practical choice for industrial environments.
Technical Specifications Breakdown
The Schneider ABFS08H202 offers critical parameters for integration. Below is a detailed specification table based on manufacturer data.
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Type |
Cable Module |
| Product Line |
Modicon Quantum |
| Connector Type |
HE-08 |
| Cable Length |
2 meters |
| Signal Type |
Analog I/O |
| Number of Conductors |
8 conductors |
| AWG Gauge |
AWG 22 |
| Humidity Tolerance |
95% relative humidity, non-condensing |
| Connector Pitch |
2.54 mm |
| Compliance |
RoHS compliant |
| Operating Temperature Range |
–20 °C to +60 °C |
| Insulation Material |
PVC |
| Cable Construction |
Multi-conductor shielded cable |
| Mounting |
Plug-and-play |
| Current Rating |
2A |
| Voltage Rating |
250 V |
The Schneider ABFS08H202 handles up to 250 V and 2A, suitable for typical analog I/O circuits. Its shielded construction reduces electromagnetic interference, ensuring signal integrity in noisy environments.
Installation & Setup Guidance
Installing the Schneider ABFS08H202 is straightforward due to its plug-and-play design. Simply connect the HE-08 connector to the matching port on your Modicon Quantum module. Ensure the cable is routed away from high-voltage lines to maintain signal quality. The 2-meter length offers flexibility for panel layouts. No special tools are required, and the connector's 2.54 mm pitch aligns with standard I/O modules.
Maintenance & Reliability
The Schneider ABFS08H202 requires minimal maintenance. Its PVC insulation resists wear, and the shielded cable prevents noise degradation. With an operating range of -20 °C to +60 °C and 95% humidity tolerance, this module suits demanding conditions. Regular visual inspections for connector damage or cable abrasion help ensure long-term reliability. The RoHS compliance also aligns with environmental standards.
Selection Guide & Purchasing Advice
When ordering the Schneider ABFS08H202, verify compatibility with your Modicon Quantum system. Confirm the I/O module uses an HE-08 connector. This cable supports analog signals only; avoid use for digital or power applications beyond 2A. For a reliable source, PLC Source PRO (ubest101) stocks genuine parts and expedites shipping for industrial clients.
