Product Introduction
When you need a dependable connection for analog current signals in Modicon Quantum automation systems, the Schneider ABFM08S202 cabled connector provides a robust solution. This industrial automation module is engineered for eight-channel analog current input signals, ensuring a stable and shielded electrical link. As part of the Modicon Quantum product line, the Schneider ABFM08S202 combines durability with precision, making it a trusted component for control system integration.
Technical Specifications Breakdown
The Schneider ABFM08S202 offers key technical parameters that define its performance and application suitability. It features 8 channels, a cable length of 6.6 ft (2 m), and uses a SUB-D connector with 25 ways. The AWG 24 wire section of 0.22 mm² supports efficient signal transmission. With a current rating of 1 A and voltage rating of 250 V, this connector is rated for industrial environments. The operating temperature range of -20 °C to +60 °C ensures reliable operation in varied conditions.
Below is a summary of the core specifications:
| Parameter |
Value |
| Number of Channels |
8 |
| Cable Length |
6.6 ft (2 m) |
| Signal Type |
Analog current input signals |
| Electrical Connection |
1 connector (SUB-D, 25 ways) |
| AWG Gauge |
AWG 24 |
| Wire Section |
0.22 mm² |
| Current Rating |
1 A |
| Voltage Rating |
250 V |
| Operating Temperature Range |
-20 °C to +60 °C |
| Insulation Material |
PVC |
| Cable Construction |
Multi-conductor, shielded cable |
| Net Weight |
0.99 lb (0.45 kg) |
Compatibility & Integration
The Schneider ABFM08S202 is designed for direct compatibility with Modicon Quantum PLC systems. It is specifically compatible with the 140AC013000 module, ensuring seamless connection for analog input applications. This cabled connector integrates easily into existing control cabinets and is suitable for both new installations and replacements of older connectors within the Modicon Quantum family.
Installation & Setup Guidance
When installing the Schneider ABFM08S202, ensure that the SUB-D connector is securely fastened to the module receptacle. The shielded cable should be routed away from high-voltage lines to avoid signal interference. Use the appropriate strain relief for the cable to maintain integrity. Verify that the wire section of 0.22 mm² and AWG 24 gauge are properly terminated at both ends. The connector’s 25 ways provide ample pinout options; refer to the system documentation for correct wiring assignments.
Maintenance & Reliability
Designed for long-term reliability, the Schneider ABFM08S202 features PVC insulation and a multi-conductor shielded cable that resists electrical noise. The operating temperature range from -20 °C to +60 °C allows deployment in demanding industrial environments. Routine inspection should focus on cable integrity and connector contact cleanliness. With proper handling, this connector can maintain stable connections over extended periods, reducing downtime and maintenance costs.
Selection Guide & Purchasing Advice
Before purchasing the Schneider ABFM08S202, verify that your system uses Modicon Quantum PLC and confirm compatibility with the target module (e.g., 140AC013000). Ensure that the required number of channels (8) meets your application needs. The 6.6 ft cable length is suitable for typical cabinet-to-module connections. For reliable supply, you can procure this part from trusted sources like ubest101, which specializes in industrial automation spares.
