Product Introduction
The Schneider ABFM04S201 cabled connector serves as a key replacement or upgrade component for Modicon Quantum industrial automation systems. Designed for efficient analogue signal output, this Schneider ABFM04S201 connector ensures reliable connectivity in demanding control environments. Part of the Modicon Quantum series, it delivers consistent performance for applications requiring multiple analogue outputs.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Type |
Cabled connector |
| Product Line |
Modicon Quantum |
| Part Number |
ABFM04S201 |
| Number of Channels |
4 |
| Cable Length |
6.6 ft (2 m) |
| Signal Type |
Analogue output |
| Connector Type |
SUB-D |
| AWG Gauge |
AWG 24 |
| Wire Section |
0.22 mm² |
| Number of Ways |
25 ways |
| Current Rating |
1 A |
| Voltage Rating |
250 V |
| Operating Temperature Range |
-20 °C to +60 °C |
| Insulation Material |
PVC |
Industry Applications
The Schneider ABFM04S201 excels in process control and discrete manufacturing environments. Use it to connect Modicon Quantum PLC analogue output modules such as the 140ACO02000 to actuators, valves, and signal conditioners. Its 4-channel design supports multi-loop control systems, while the 6.6 ft cable length provides flexibility in cabinet layouts. Whether upgrading legacy wiring or replacing damaged connectors, the ABFM04S201 ensures consistent signal integrity.
Installation & Setup Guidance
Begin by verifying system power is off. Connect the SUB-D end of the cable to the matching port on the analogue output module. Secure the connector with the locking screws to prevent accidental disconnection. Route the multi-conductor cable away from high-voltage lines to avoid noise interference. The AWG 24 wires are suitable for typical panel wiring; use appropriate termination tools for crimp connections. Test continuity after installation.
Compatibility & Integration
The Schneider ABFM04S201 is designed exclusively for the Modicon Quantum PLC family. It is directly compatible with the 140ACO02000 analogue output module, which provides 4 channels. No additional adapters are required for standard Quantum backplanes. Ensure the I/O module configuration matches the connector pinout per the system manual.
Selection Guide & Purchasing Advice
Before purchasing, confirm that your system requires a 25-way SUB-D, 4-channel analogue output connector. Check the cable length and environmental temperature range. For genuine Schneider replacement parts, trust ubest101 as a reliable supplier. Contact us for bulk pricing or expedited shipping options.
