Product Overview
When industrial cable systems demand reliable connections, the Schneider 990XTS00300 Modular Conversion Connector delivers robust performance. Part of the Modicon Quantum series, this connector is designed for long-term service in demanding environments. Its industrial-grade plastic construction and panel mountable design provide both durability and installation flexibility, minimizing maintenance costs and maximizing uptime.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Type |
Conversion Connector |
| Product Line |
Modicon Quantum |
| Part Number |
990XTS00300 |
| UPC |
785901149897 |
| Connector Type |
Modular Connector |
| Electrical Connection |
1 x Connector |
| Current Rating |
10A |
| Material |
Industrial-grade Plastic |
| Mounting Type |
Panel Mountable |
| Temperature Range |
-10°C to 60°C |
| Compatibility |
Industrial Cable Systems |
| Cable Type |
Cable Module |
| Environmental Protection |
IP20 (Front Protection) |
| Rated Voltage |
250 VDC |
The 10A current rating ensures reliable power handling for medium loads in control circuits, while the 250 VDC rating suits DC applications. The IP20 front protection guards against dust ingress in indoor settings. This combination of specs makes the 990XTS00300 a cost-effective choice for reducing downtime.
Real-World Applications
The Schneider 990XTS00300 excels in connecting control panels to field devices. Common uses include:
- Interfacing with programmable logic controllers (PLCs) in industrial automation lines.
- As a conversion point between cable types in distributed control systems (DCS).
- Within motor control centers for reliable wiring connections.
Its wide -10°C to 60°C temperature tolerance makes it suitable for environments with moderate thermal variation, reducing the risk of connector failure.
Installation & Setup
Panel mounting simplifies installation. Follow these steps for best results:
- Ensure the panel cutout matches the connector dimensions.
- Secure the connector using appropriate fasteners (not supplied).
- Align the cable module connector properly to avoid pin damage.
- Verify electrical connections meet the 10A and 250 VDC ratings.
No special tools are required, which reduces labor time and associated costs.
Compatibility & Integration
The Schneider 990XTS00300 is designed for Modicon Quantum systems and is compatible with various industrial cable systems. It supports cable modules, making it versatile for many setups. While primarily a passive connector, it integrates seamlessly into existing wiring schemes without protocol conflicts.
Selection Guide & Purchasing Advice
When selecting this connector, verify compatibility with your cable type and panel dimensions. For bulk ordering or custom requirements, contact PLC Source PRO (via the store link at ubest101) to ensure availability and the best pricing. Choosing the 990XTS00300 means investing in a proven component that reduces replacement frequency and maintains signal integrity.
