Product Overview
The Schneider 690MCB00000 field wiring block is a breakout module designed for motion control applications within the Modicon Quantum series. It simplifies wiring by providing a central interface between the controller and field devices, reducing installation time and potential failure points. This robust module supports up to 50 screw terminals, ensuring secure and organized connections.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Part Number |
690MCB00000 |
| Product Line |
Modicon Quantum |
| Weight |
1.06 lbs (0.48 kg) |
| Number of Screw Terminals |
50 |
| Connector Type |
50-pin male connector |
| Mounting |
Panel-mounted |
| Dimensions (H x W x D) |
4.13 in x 7.09 in x 10.43 in (105 mm x 180 mm x 265 mm) |
| Compatibility |
Modicon systems |
Industry Applications
The 690MCB00000 excels in automated manufacturing lines, packaging machinery, and conveyor systems where precise motion control is critical. Its breakout design allows quick field wiring changes during setup or maintenance, reducing downtime. For example, in a robotic assembly cell, the module enables fast reconfiguration of sensor and actuator connections without disturbing the main controller.
Installation & Setup Guidance
Mount the panel using the provided screw holes. Connect the 50-pin male connector to the corresponding cable from the controller. Label each screw terminal according to your wiring diagram to simplify future troubleshooting. Ensure wires are stripped to proper length and tightened to the recommended torque to avoid loose connections. The module's compact footprint fits easily into standard enclosures.
Compatibility & Integration
Designed specifically for Modicon Quantum systems, the 690MCB00000 seamlessly integrates with Schneider motion controllers and I/O modules. It supports both new installations and upgrades of existing field wiring blocks. Verify that your controller's motion control module has a compatible 50-pin female connector.
Selection Guide & Purchasing Advice
Before purchasing, confirm that your application requires a breakout module with 50 screw terminals. If your system uses fewer connections, consider alternative models. For guaranteed authenticity and fast shipping, choose PLC Source PRO as your supplier (visit ubest101.myshopify.com for more product details). Our inventory includes new and tested surplus units at competitive prices.
