Product Overview
The 171CCC96020C processor adaptor from Schneider Electric's Modicon Momentum series is designed for demanding industrial control tasks. With an x86-based architecture clocked at 50 MHz, it delivers reliable processing for mid-range automation systems. The unit operates from 0°C to 60°C and is built to integrate seamlessly with the Momentum I/O base.
Key Specifications
-
Part Number: 171CCC96020C
-
Brand: Schneider Electric
-
Product Type: Processor Adaptor
-
Product Line: Modicon Momentum
-
CPU Architecture: x86-based, 50 MHz
-
Memory: 512 KB Flash, 544 KB RAM
-
Communication Ports: 1 Ethernet (Modbus TCP, I/O scan), 1 I/O bus
-
Supply Voltage: 5 VDC ±5%
-
Operating Temperature: 0°C to 60°C
-
Protective Coating: Conformal (Humiseal 1A33)
-
Word Length: 16-bit
-
I/O Capacity (Discrete): 8192 In / 8192 Out
-
I/O Capacity (Registers): 26048 In / 26048 Out
-
Program Memory: 18 KB (LL984)
-
Data Memory: 24 KB
Technical Specifications Breakdown
The 171CCC96020C features a 50 MHz x86 processor that handles complex logic with ease. Its 512 KB Flash and 544 KB RAM provide ample space for application code and data. The 16-bit word length ensures compatibility with standard industrial data formats. With 8192 discrete inputs and outputs plus over 26000 register points, this module suits large-scale I/O applications.
Industry Applications
In manufacturing lines, the 171CCC96020C manages high-speed discrete control and data acquisition. For process industries, its Modbus TCP port enables integration with SCADA systems. The wide temperature range and conformal coating make it suitable for harsh factory environments.
Installation & Setup Guidance
Mount the 171CCC96020C directly onto a Momentum I/O base. Connect the Ethernet port to your control network using standard Category 5e cables. Verify the 5 VDC supply voltage is within ±5% tolerance. Use the I/O bus for local expansion modules.
Maintenance & Reliability
Inspect the protective conformal coating annually for cracks or damage. Keep the unit within the 0°C to 60°C operating range to ensure long service life. Clean dust from ventilation slots using compressed air.
Compatibility & Integration
The 171CCC96020C works with all Modicon Momentum I/O bases and remote I/O modules. It supports Modbus TCP for Ethernet communication and uses the LL984 programming language. Integrate with Schneider Electric PLCs and third-party systems via the open protocol.
Selection Guide & Purchasing Advice
Before purchasing, verify that your system requires a 5 VDC ±5% supply and that the Momentum I/O base is available. The 171CCC96020C is a direct replacement for earlier Modicon Momentum processor adaptors. For assistance, contact PLC Source PRO at ubest101 for pricing and availability.
