Product Introduction
When seeking a dependable field power connector for Modicon Quantum automation platforms, the Schneider 140XTS00500 delivers robust performance. This seven-pin connector from Schneider Electric ensures secure power distribution to compatible power supply modules, simplifying system integration and enhancing overall reliability.
Technical Specifications Breakdown
The Schneider 140XTS00500 offers key specifications tailored for industrial use:
-
Number of Pins: 7 pins
-
IP Degree of Protection: IP20 ( protects against solid objects >12.5 mm; not moisture-resistant)
-
Weight: 0.31 lbs (0.14 kg) to 0.33 lbs (0.15 kg) – lightweight for easy handling
-
Dimensions: Approx. 0.98 x 3.94 x 5.91 inches (25 x 100 x 150 mm)
-
Product Compatibility: Works with 140CPS21400, 140CPS22400, 140CPS11420, 140CPS51100, 140CPS11100, 140CPS21100, 140CPS52400, 140CPS12420, 140CPS41400, 140CPS42400
These parameters confirm the Schneider 140XTS00500 is designed for integral use within Modicon Quantum systems, ensuring reliable power connections.
Industry Applications
The Schneider 140XTS00500 field power connector is ideal for internal cabinet applications where dust and limited moisture exposure occur. Common use cases include:
-
Automated production lines – connecting power supplies to Quantum PLC modules for continuous operation.
-
Process control systems – ensuring stable power distribution in chemical, oil and gas, or water treatment plants.
-
Machine tool control – powering control units in CNC machines and robotic cells.
Thanks to its IP20 rating, the Schneider 140XTS00500 suits clean, indoor environments where minimal particle ingress is expected.
Installation & Setup Guidance
To install the Schneider 140XTS00500, follow these steps for safe and reliable operation:
- Verify the target power supply module is one of the compatible 140CPS models listed above.
- Ensure the system is de-energized before connecting or disconnecting the field power connector.
- Align the seven pins carefully to avoid bending. Insert firmly until the locking mechanism engages.
- Route cables to avoid sharp bends and secure them to prevent strain on the connector.
Do not overtighten screws if present; the connector is designed for a snug fit without excessive force.
Maintenance & Reliability
Regular inspection of the Schneider 140XTS00500 connector helps maintain system uptime. Check for corrosion, bent pins, or loosened connections every six months. Since the connector has an IP20 rating, keep it in clean, dry enclosures. Promptly replace damaged connectors to avoid power failure. The lightweight design (0.15 kg) simplifies handling during maintenance.
Selection Guide & Purchasing Advice
Before purchasing the Schneider 140XTS00500, confirm compatibility with your existing power supply module – it works specifically with the 140CPS series listed. No additional adapters are required. For bulk orders or technical support, contact UBEST Automation (ubest101) for professional guidance. Choose the Schneider 140XTS00500 for a cost-effective, reliable field power connector that enhances your Modicon Quantum system's performance.
