Product Introduction
When you need to expand your Modicon Quantum backplane reliably, the Schneider 140XCA71706 backplane expander cable delivers exactly what you require. This cable is designed specifically for Modicon Quantum systems, providing a robust 2-meter connection using PROFIBUS connectors at both ends. Part of Schneider Electric's trusted product line, the 140XCA71706 ensures seamless communication between field devices and the controller.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon Quantum |
| Part Number |
140XCA71706 |
| Weight |
1.00 lbs (0.45 kg) |
| Product Type |
Backplane Expander Cable |
| Cable Length |
2 m |
| Connectors Position |
At Both Ends |
| Connector Types |
PROFIBUS |
| Material |
PVC |
| Maximum Ambient Temperature |
60 °C |
| Minimum Ambient Temperature |
0 °C |
| Operating Humidity |
Up to 80% (non-condensing) |
| Storage Humidity |
Up to 80% (non-condensing) |
| Maximum Operating Altitude |
1000 m above sea level |
| Protection Class |
IP20 |
| Certifications |
CE |
Compatibility & Integration
The Schneider 140XCA71706 integrates seamlessly with any Modicon Quantum system requiring backplane expansion. Its PROFIBUS connectors ensure reliable communication with a wide range of field devices and controllers. This cable is also compatible with other Schneider automation components that use PROFIBUS interface standards, simplifying system upgrades and replacements.
Installation & Setup Guidance
Install the 140XCA71706 by connecting each end to the appropriate backplane module or device. Ensure the cable is not bent beyond its minimum bend radius to prevent signal degradation. Use cable ties to secure the cable away from sharp edges or heat sources. The IP20 rating means it is suitable for use in clean, dry environments; avoid exposure to excessive dust or moisture. For best results, follow Schneider's recommended installation practices for Modicon Quantum systems.
Replacement & Upgrade Guide
Upgrading from older backplane cables to the Schneider 140XCA71706 brings better reliability and connectivity. The PVC jacket provides good durability, while the PROFIBUS connectors ensure secure contact. When replacing a cable, always power down the system first. Verify the cable length and connector type match your application. This cable serves as a direct replacement for original Schneider backplane expander cables in Quantum systems. For purchasing, contact a trusted supplier like ubest101 to ensure genuine parts.
