Product Introduction
When industrial automation demands fast and reliable field-level communication, the Schneider 140EIA92100C AS interface master module delivers. Part of the Modicon Quantum family, this AS-i V1 master module handles up to 31 server devices with a maximum cycle time of just 5 milliseconds. It provides 124 discrete inputs and 124 discrete outputs, making it a robust choice for real-time control applications.
Technical Specifications Breakdown
The Schneider 140EIA92100C integrates critical performance parameters that ensure efficient data exchange. Below are the key specifications derived from the product datasheet:
| Parameter |
Value |
| AS-i Version |
V1 |
| Maximum Cycle Time |
5 ms |
| Discrete Inputs / Outputs |
124 each |
| Server Devices |
31 |
| Transmission Rate |
167 kbit/s |
| Current Consumption |
≤ 100 mA |
| Protection Class |
IP20 |
| Ambient Temperature |
0 to 60 °C |
These specifications make the Schneider 140EIA92100C a reliable choice for high-speed data acquisition and control in demanding industrial environments.
Real-World Application Scenarios
The Schneider 140EIA92100C excels in assembly lines where fast sensor-to-controller communication is critical. In packaging machinery, its 5 ms cycle time ensures precise timing for product handling. Material handling systems benefit from the 124 I/O channels that allow connection of numerous sensors and actuators, reducing wiring complexity via the AS-Interface cabling system.
Installation & Setup Guidance
Mount the Schneider 140EIA92100C in a Modicon Quantum local or remote drop (up to 4 per PLC drop). Connect the AS-Interface line using the provided SUB-D 3-pin male connector. Ensure reverse polarity protection is active (internal). Set the addressing to standard mode. The module supports a bus length up to 100 m without a repeater. For best performance, maintain ambient temperature between 0 and 60 °C.
Compatibility & Integration
The Schneider 140EIA92100C integrates seamlessly with the Modicon Quantum automation platform. It works with up to 31 AS-Interface server devices and is compatible with the AS-Interface cabling system. For larger systems, up to 4 modules per PLC distributed drop can be used. The module carries CE, UL, FM, CSA, and other certifications, ensuring global compliance.
Selection Guide & Purchasing Advice
Before purchasing the Schneider 140EIA92100C, verify that your system uses AS-i V1 and standard addressing. Confirm the number of required I/O points: this module supports 124 inputs and 124 outputs. For reliable supply, choose UBEST Automation (visit ubest101.myshopify.com) — a trusted source for industrial automation spares. Ensure your PLC rack has an available slot and that the ambient conditions meet IP20 requirements.
