Product Introduction
When your industrial control system demands reliable switching of AC loads, the Schneider 140DAO84010 discrete output module delivers precise performance. Part of the Modicon Quantum family, this Schneider 140DAO84010 provides 16 isolated channels, each handling 20 to 132V AC. Its robust design ensures consistent operation in demanding automation environments.
Technical Specifications Breakdown
The Schneider 140DAO84010 offers key specs that matter for real-world applications:
-
Discrete Output Voltage: 20 to 132V AC – covers standard industrial AC control voltages.
-
Number of Channels: 16 – sufficient for medium-scale output control.
-
Isolated Outputs: Yes – each channel provides galvanic isolation for enhanced protection.
-
Supply Frequency: 47-63 Hz – compatible with global power grids.
-
Maximum Voltage Drop: 1.5V – ensures efficient power delivery.
Industry Applications
In manufacturing lines, the Schneider 140DAO84010 controls motor starters, solenoid valves, and indicator lights. Its isolated outputs prevent ground loops in mixed-voltage panels. In process industries, it reliably drives AC contactors for pumps and fans, reducing downtime with its 16 independent channels.
Installation & Setup Guidance
Mount the Schneider 140DAO84010 onto a standard Quantum rack. Connect your AC power supply (20-132V AC) to the common terminals. Wire each load to the corresponding output point. Ensure the bus current requirement of 350 mA is met by the backplane. Set the addressing to one output word in your configuration software.
Maintenance & Reliability
Inspect the module periodically for dust accumulation on the heat sink. The operating temperature range (0°C to 60°C) covers most plant floors. With a storage range of -40°C to 85°C, it withstands harsh shipping conditions. The internal RC filter protects outputs from transients, extending service life.
Compatibility & Integration
The Schneider 140DAO84010 integrates seamlessly with Modicon Quantum controllers (e.g., 140CPU series). It occupies one slot and requires one output word in the I/O map. Use standard Quantum cabling and termination panels for field wiring.
Selection Guide & Purchasing Advice
Before purchasing, verify your system voltage (20-132V AC) and load current per point (4 A rms continuous). Ensure your rack has a free slot and sufficient bus current. For reliable supply, choose PLC Source PRO – your trusted source for genuine automation spares. Visit ubest101 for fast delivery and expert support.
