Product Introduction
The Schneider 140ARI03000C is a high-performance RTD input module from Schneider Electric, specifically designed for the Modicon Quantum series. This module provides eight dedicated channels for precise temperature measurement, utilizing sigma-delta technology for analog-to-digital conversion. With an input resolution of 15 bits, the 140ARI03000C delivers accurate readings essential for industrial process control. Its robust noise rejection capabilities, including a 120 dB common mode rejection ratio and 60 dB differential mode rejection, ensure reliable operation in electrically noisy environments. The module supports internal recalibration, simplifying maintenance and long-term accuracy.
Technical Specifications Breakdown
The Schneider 140ARI03000C offers the following key specifications based on manufacturer data:
-
Channels: 8 dedicated RTD inputs
-
Input Resolution: 15 bits
-
ADC Method: Sigma-delta conversion
-
Common Mode Rejection: 120 dB
-
Differential Mode Rejection: 60 dB
-
Recalibration: Internal, simplifying field adjustments
-
Altitude: 0 to 2000 m operating range
-
Ambient Temperature: 0 to 60 °C operation; -40 to 85 °C storage
-
Protection Class: IP20
-
Weight: 209 grams
These parameters enable the 140ARI03000C to deliver consistent performance across diverse industrial settings. The high common mode rejection reduces interference from ground loops, while the internal recalibration feature minimizes downtime for calibration.
Industry Applications
The Schneider 140ARI03000C is ideal for applications requiring precise temperature monitoring and control. Typical use cases include:
-
Chemical Processing: Accurate RTD measurements ensure proper reaction temperatures, reducing waste and improving yield.
-
HVAC Systems: Monitoring of heating and cooling loops in large facilities benefits from the module’s noise immunity and stability.
-
Power Generation: Turbine bearing temperatures and transformer oil temperatures can be reliably tracked, supporting preventive maintenance strategies.
By choosing the 140ARI03000C, operators gain long-term cost benefits through reduced measurement errors and fewer recalibration cycles.
Installation & Setup Guidance
When installing the Schneider 140ARI03000C in a Modicon Quantum backplane, ensure the module is seated securely and the locking mechanism is engaged. Connect RTD sensors to the appropriate screw terminals, observing correct wiring polarity for three-wire or four-wire configurations. The module supports internal recalibration, but initial setup may require configuring input ranges via the control system software. Always verify that the ambient temperature stays within the 0 to 60 °C range and that the enclosure provides adequate ventilation. For optimum noise performance, keep RTD wiring away from high-power cables.
Compatibility & Integration
The 140ARI03000C is fully compatible with the Modicon Quantum programmable automation controllers (PACs) from Schneider Electric. It integrates seamlessly into existing Quantum racks, communicating via the backplane bus. The module does not require external power supplies beyond the rack power. No specific communication protocols are listed in the manufacturer data, so users should consult the system manual for addressing and configuration details within the Unity Pro or Control Expert software environment.
Selection Guide & Purchasing Advice
Before purchasing the Schneider 140ARI03000C, verify that your system uses a Modicon Quantum backplane with available slots. Ensure that the RTD sensor types match the module’s input range (not specified, but typically PT100, PT1000, Ni100, etc.). For replacement or upgrade, confirm the exact part number and revision level. As a reliable supplier, UBEST Automation offers this module with fast shipping and authentic inventory – contact us for availability. For other industrial automation spares, check our catalog at ubest101.
