Product Introduction
With a power output of 0.75 kW and a compact footprint, the KEB 07F5A1A-3E2F Combivert Axis Drive provides precise control for diverse automation tasks. This drive operates reliably in controlled indoor environments thanks to its IP20 rating, which safeguards against solid object ingress. Its advanced thermal management system maintains stable performance between -10°C and +45°C, while short-circuit and earth fault monitoring per EN 60204-1 prevent common failure modes. The 8/16 kHz switching frequency reduces electromagnetic interference, ensuring compliance with EN 61800-3 and EN 61000-6 standards.
Key Technical Specifications
| Parameter |
Value |
| Cooling Method |
Air-cooled |
| EMC Standard Compliance |
EN 61800-3 and EN 61000-6 |
| Integrated Filter |
Complies with EN 55011/C1 |
| Maximum Current |
4.7 A |
| Operating Temperature Range |
-10 to +45°C |
| Phase |
3 |
| Protection |
IP20 |
| Rated Current |
2.6 A |
| Rated Power |
0.75 kW |
| Safety Features |
ISO 13849 and SIL 3 as per IEC 62061 |
| Short-Circuit and Earth Fault Monitoring |
Compliance with EN 60204-1 |
| Storage Temperature Range |
-25 to +70°C |
| Switching Frequency |
8/16 kHz |
| Voltage Class |
305 to 528 VAC |
| Warranty |
One-year |
Industry Applications
The KEB 07F5A1A-3E2F excels in applications requiring accurate low-power motor control. Typical use cases include conveyor systems, packaging machinery, and material handling equipment. Its integrated EMC filter and selectable switching frequencies allow it to operate alongside sensitive electronics without causing interference. The dual-channel optocoupler braking with SIL 3 certification ensures safe deceleration in emergency stops, reducing the risk of mechanical damage.
Reliability and Maintenance
Air-cooled thermal management keeps the KEB 07F5A1A-3E2F within its operating range during continuous duty. The IP20 enclosure requires installation in a clean, dry cabinet to prevent dust accumulation. Periodic inspection of cooling vents and cable connections is recommended. Monitoring earth fault and short-circuit conditions per EN 60204-1 helps avoid unplanned downtime. The drive's robust design supports reliable operation over its service life when used within specified voltage and environmental limits.
Selection Guide
Before purchasing the KEB 07F5A1A-3E2F, verify that your system provides a 3-phase supply between 305 and 528 VAC. Confirm that the load current does not exceed 2.6 A rated or 4.7 A peak. For additional harmonic mitigation, an external filter may be used (not included). UBEST Automation (ubest101.myshopify.com) offers this drive with a one-year warranty and technical support. Ensure compatibility with your motor and control interface.
