Product Overview
The GE TB810 Modulebus Optical Port is a dedicated communication module engineered for industrial automation environments. This compact unit provides a reliable optical interface for Modulebus networks, ensuring stable data transmission in demanding applications. The TB810 is an essential component for systems requiring robust connectivity and minimal footprint.
Technical Specifications
| Parameter |
Value |
| Product Type |
Communication_Module |
| Product ID |
3BSE008560R1 |
| ABB Type Designation |
TB810 |
| Net Depth / Length |
20 mm |
| Net Height |
40 mm |
| Net Width |
40 mm |
| Net Weight |
0.035 kg |
| RoHS Compliance |
Following EU Directive 2011/65/EU |
| WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
| Number of Batteries |
0 |
Key Features & Benefits
-
Optical Port Interface: The TB810 provides a fiber-optic connection for Modulebus, offering electrical isolation and noise immunity—critical for harsh industrial settings.
-
Ultra-Compact Design: With dimensions of just 40 mm x 40 mm x 20 mm and a weight of 0.035 kg, the TB810 fits easily into tight control panels without adding significant bulk.
-
RoHS Compliant: Manufactured in accordance with EU Directive 2011/65/EU, ensuring environmental responsibility and regulatory compliance.
-
Battery-Free Operation: With zero batteries, the TB810 eliminates the need for periodic battery replacement, reducing maintenance overhead.
Applications
The GE TB810 Modulebus Optical Port is ideal for use in industrial control systems where reliable communication between modules is essential. Typical applications include:
- Distributed control systems (DCS) requiring optical isolation between field devices and controllers.
- Process automation networks where electromagnetic interference is a concern.
- Retrofit projects where existing copper connections are replaced with fiber optics for improved reliability.
In each scenario, the TB810 ensures data integrity and minimizes downtime, contributing to higher operational efficiency.
Installation & Setup
Installing the TB810 is straightforward. The module mounts on a DIN rail or panel using standard hardware (not included). Connect the optical fiber to the port, ensuring a clean and secure fit. No special tools are required. Always power down the system before installation to avoid damage.
Maintenance & Reliability
Thanks to its solid-state design and lack of moving parts, the TB810 requires minimal maintenance. Periodically inspect the optical connections for dust or debris and clean them with appropriate fiber-optic cleaning supplies. The compact enclosure protects internal components from dust and vibration, ensuring long service life.
Compatibility & Integration
The TB810 is designed for use within ABB Modulebus-based systems. It integrates seamlessly with compatible ABB controllers and I/O modules, providing a standardized optical interface. Verify system compatibility before ordering to ensure optimal performance.
Buying Guide
When selecting the GE TB810, confirm your system's communication requirements and physical mounting constraints. The module's small footprint makes it versatile, but always double-check dimensions against your enclosure. For genuine parts and reliable sourcing, PLC Source PRO offers the TB810 with full specification transparency.
