Product Introduction
When your automation system requires reliable switching for multiple loads, the GE IC693MDL940 relay output module from the Series 90-30 provides a robust solution. Designed for versatile outputs, this module accommodates up to 16 outputs arranged in four isolated groups of four, allowing organized control across varying voltage levels. Whether for DC or AC applications, the IC693MDL940 delivers consistent performance in demanding industrial environments.
Technical Specifications
The table below lists the key parameters of the GE IC693MDL940. All values are taken directly from the manufacturer's data.
| Parameter |
Value |
| Manufacturer |
GE Fanuc Emerson |
| Series |
Series 90-30 |
| Module Type |
Relay Output Module |
| Total Number of Outputs |
16 Outputs |
| Output Groups |
4 Groups of 4 Outputs Each |
| Maximum Load Current per Output |
2A |
| Maximum Load Current per Common |
4A |
| Nominal Rated DC Voltage |
24V DC |
| Nominal Rated AC Voltage |
120/240V AC |
| DC Operating Voltage |
5-30V DC |
| AC Operating Voltage |
5-250V AC, 50/60 Hz |
| Minimum Load Current |
10 mA |
| Maximum Inrush Current |
5A |
| Maximum Response Time (On and Off) |
15 ms |
These specifications highlight the GE IC693MDL940's flexibility. With a wide AC/DC voltage range, it can interface with both legacy and modern equipment. The 2A per output capacity handles moderate loads, while the 4A common current provides headroom for grouped outputs. The 15 ms response time ensures quick switching in time-sensitive processes.
Industry Applications
The IC693MDL940 excels in applications requiring multiple discrete outputs. Typical use cases include:
-
Conveyor Systems: Control motor starters and solenoids with the 16 relay outputs, each capable of switching 24V DC or 120V AC loads.
-
Packaging Machinery: Use the grouped outputs to handle actuators for cutting, sealing, and labeling stations, benefiting from the 4A common current per group.
-
HVAC Control: Manage fans, dampers, and pumps with the module's AC operating voltage range up to 250V AC.
The reliability of the GE IC693MDL940 reduces downtime, directly improving operational efficiency and lowering total cost of ownership.
Maintenance & Reliability
Relay output modules like the IC693MDL940 are generally robust, but periodic checks can extend service life. Inspect the module's indicator LEDs for proper operation of each output. Ensure the load current remains within the 2A per output limit and the total common current does not exceed 4A. Avoid exceeding the 5A inrush current rating during startup to prevent contact welding. In environments with frequent switching, consider derating the load to prolong relay life. The GE IC693MDL940 is designed for easy replacement within the Series 90-30 rack, minimizing downtime.
Selection Guide & Purchasing Advice
Before ordering, verify that your rack and backplane support the IC693MDL940. It fits standard Series 90-30 slots. No special accessories are required, but ensure you have the correct wiring base. For best performance, pair with GE Fanuc's recommended power supplies and CPUs. UBEST Automation supplies genuine, inspected IC693MDL940 modules ready for immediate deployment. Check stock at ubest101.
