Product Introduction
When drive systems encounter regenerative braking, excess energy must be dissipated to prevent voltage spikes and component damage. The GE 3HAC035583-001 Bleeder 1,8 kW Assembly is designed for use in low voltage (LV) drive systems, specifically for Drive System 09 applications. This robust unit safely converts kinetic energy into heat, protecting your inverter and motor from overvoltage conditions. As a key component for dynamic braking, the GE 3HAC035583-001 ensures your system operates within safe limits, reducing downtime and extending equipment life.
Technical Specifications
The GE 3HAC035583-001 is a precision-engineered bleeder resistor assembly. Below are the detailed specifications from the manufacturer:
| Specification |
Value |
| Product ID |
3HAC035583-001 |
| Catalog Description |
Bleeder 1,8 kW ass. |
| Minimum Order Quantity |
1 piece |
| Selling Unit of Measure |
piece |
| Order Multiple |
1 piece |
| Country of Origin |
China |
| Product Net Weight |
1.85 kg |
| Gross Weight |
1.85 kg |
| Product Net Depth / Length |
1600 mm |
| Product Net Height |
27 mm |
| Product Net Width |
160 mm |
| Customs Tariff Number |
85168080 |
| Frame Size |
Spare_Parts |
The long, slim form factor (1600 mm x 160 mm x 27 mm) is designed to mount conveniently inside drive cabinets, optimizing space while providing adequate thermal dissipation.
Industry Applications
The GE 3HAC035583-001 is ideally suited for low voltage drive systems requiring dynamic braking. Common applications include:
-
Conveyor Systems: Frequent stopping and starting generate regenerative energy that this bleeder resistor safely dissipates.
-
Cranes and Hoists: Lowering heavy loads demands controlled braking; the GE 3HAC035583-001 delivers consistent performance.
-
Elevators and Lifts: Regenerative power from descending cars is effectively managed to prevent nuisance trips and component stress.
In each scenario, the resistor's 1.8 kW power rating handles continuous duty cycles, reducing the risk of thermal runaway—a common failure mode in undersized bleeder assemblies.
Installation & Setup Guidance
Mount the GE 3HAC035583-001 securely on a flat, non-flammable surface within the drive cabinet. Ensure adequate clearance around the unit for natural air convection; do not enclose in a sealed compartment. Connect the resistor terminals to the drive's dynamic braking output using appropriately rated cables. Verify that the drive's braking chopper is configured to engage at the correct voltage. For systems with multiple resistors, wire them in parallel only as specified by the drive manufacturer.
Maintenance & Reliability
To maximize the service life of the GE 3HAC035583-001, inspect the resistor element annually for signs of cracking or discoloration. Check terminal connections for tightness and corrosion. In dusty environments, clean the fins with compressed air to prevent insulation buildup. The assembly's robust construction—housed in a metal chassis—ensures reliable heat transfer and mechanical stability. Regular maintenance prevents the most common failure mode: gradual performance degradation due to thermal cycling and contamination.
Troubleshooting & Common Issues
-
Overheating: If the GE 3HAC035583-001 becomes excessively hot, verify that the drive's braking duty cycle does not exceed the resistor's 1.8 kW rating. Also check for blocked airflow.
-
No Braking Effect: Inspect the wiring between the drive and the resistor for breaks or loose connections. Measure resistance across the terminals; an open circuit indicates a failed resistor element.
-
Frequent Drive Faults: Ensure the brake transistor or chopper in the drive is functioning. A faulty chopper can cause continuous current through the resistor, leading to premature failure.
Replacing a failed unit with the identical GE 3HAC035583-001 ensures correct power handling and mechanical fit.
Selection Guide & Purchasing Advice
Before ordering, confirm that your drive system is compatible with a 1.8 kW bleeder resistor of this physical size. The GE 3HAC035583-001 fits cabinets with at least 1600 mm of free rail length. For expert assistance or to place an order, contact UBEST Automation at ubest101.myshopify.com. We stock this unit in our warehouses in Menden, Germany and Shanghai, China, ensuring fast delivery worldwide.
