Product Overview: GE 3HAC032586-001 Bleeder Unit
The GE 3HAC032586-001 Industrial Automation Module is a dedicated bleeder unit designed for high-voltage (HV) drive systems. This new spare part ensures reliable energy dissipation and protection in demanding industrial environments. As a critical component for HV Drive System 09, the GE 3HAC032586-001 replaces aging or failed units to restore system performance and extend operational life.
Technical Specifications
The GE 3HAC032586-001 bleeder unit offers precise engineering for integration with HV drives. Key parameters include:
-
Product Net Weight: 1.64 kg
-
Gross Weight: 1.74 kg
-
ABB Type Designation: 54x13.5x5 (indicating compact dimensions for space-constrained installations)
-
Connector: 2-pole connector (part number 3HAC035373-001) for secure electrical interface
-
Intended Use: For use in HV, Drive System 09
-
Part Type: New – not remanufactured or refurbished
-
Customs Tariff Number: 85332900
These specifications ensure the GE 3HAC032586-001 meets the exact requirements of existing drive cabinets.
Real-World Applications
The GE 3HAC032586-001 bleeder unit is primarily employed in high-voltage drive systems within industries such as metals, mining, and heavy manufacturing. For example, a steel rolling mill using HV Drive System 09 can directly replace an exhausted bleeder unit with the 3HAC032586-001 to restore safe energy dumping during deceleration. This upgrade reduces downtime and avoids costly drive replacement.
Installation Guidelines
Installing the GE 3HAC032586-001 requires following standard safety protocols for HV equipment. Before mounting, ensure the drive system is de-energized and locked out. The unit mounts directly onto the designated bleeder tray or busbar assembly. Connect the 2-pole connector (3HAC035373-001) to the corresponding drive interface. Verify torque settings as per original drive documentation. After installation, perform a continuity check before re-energizing the system.
Compatibility and Integration
The GE 3HAC032586-001 is purpose-built for GE HV Drive System 09. It integrates seamlessly without modifications to existing wiring or control logic. This bleeder unit works with both existing and legacy drive cabinets provided they use the same connector type and voltage class. Always confirm the drive system model before ordering to ensure compatibility.
Selection Guide
When selecting the GE 3HAC032586-001, verify your drive system is part of the HV, Drive System 09 series. The unit is stocked in Menden, Germany, and Shanghai, China, ensuring fast delivery. As a new part, it offers immediate reliability over used alternatives. For assistance, contact UBEST Automation with your current bleeder unit details. We provide genuine spare parts to keep your operations running.
