Product Overview
The Flexem FR-T0400K is a compact, 4-channel temperature acquisition module engineered for precision measurement in demanding industrial environments. This industrial automation module accepts a wide range of thermocouple types—K, J, R, S, B, E, T, N, and C—as well as NTC and PT RTD sensors, making it a versatile solution for process monitoring and control systems.
With a slim 18 mm width and a weight of only 65 g, the FR-T0400K integrates easily into existing control panels, offering high-density temperature input without sacrificing valuable cabinet space. Its low power consumption (max 50 mA at 5.0 Vdc) ensures minimal load on your system's power supply.
Technical Specifications
| Parameter |
Specification |
| Number of Channels |
4 points |
| Sensor Types |
K, J, R, S, B, E, T, N, C thermocouples; NTC |
| Measurement Range (PT700) |
-200...850 °C |
| Measurement Range (PT1000) |
-200...600 °C |
| Measurement Range (Cu50) |
-50...150 °C |
| Measurement Range (NI100) |
-60...180 °C |
| Measurement Range (Cu100) |
-50...150 °C |
| Measurement Range (NI1000) |
-60...180 °C |
| Accuracy (at 25 °C ambient) |
±0.5% or ±1 °C (whichever greater) |
| Thermocouple Accuracy |
±0.3% or ±1 °C (whichever greater) |
| NTC Accuracy |
±0.1% or ±1 °C (whichever greater) |
| Power Consumption |
Max. 50 mA @ 5.0 Vdc |
| Dimensions (H × W × D) |
111 × 18 × 76 mm |
| Weight |
65 g |
Key Features & Benefits
-
Multi-Sensor Flexibility: Supports 9 thermocouple types plus NTC and PT RTDs, covering a broad range of temperature measurement needs.
-
High Accuracy: ±0.5% or ±1 °C accuracy ensures reliable process data, while thermocouple accuracy reaches ±0.3% or ±1 °C.
-
Compact Design: The 18 mm wide housing saves valuable panel space, ideal for high-density installations.
-
Low Power Draw: Max 50 mA at 5.0 Vdc minimizes impact on your control system's power budget.
-
Lightweight: At just 65 g, the module is easy to handle and mount.
Industry Applications
The FR-T0400K excels in applications requiring precise temperature monitoring across multiple points. Typical use cases include:
-
Process Control: Monitor temperatures in chemical reactors, heat exchangers, and storage tanks.
-
HVAC Systems: Track ambient and duct temperatures for efficient climate control.
-
Machinery Monitoring: Supervise bearing or motor temperatures to prevent overheating and downtime.
In a retrofit scenario, replacing older analog temperature scanners with the FR-T0400K streamlines wiring and improves data accuracy, directly reducing maintenance costs and unplanned shutdowns.
Installation & Setup Guidance
Proper installation ensures accurate readings and long service life. Follow these steps:
-
Mounting: Secure the module on a standard 35 mm DIN rail in a clean, dry enclosure. Ensure adequate airflow around the unit.
-
Wiring: Connect thermocouple or RTD sensors to the appropriate terminals, observing polarity. Use shielded cables for long runs to minimize electromagnetic interference.
-
Sensor Placement: Position sensors at the measurement point to reflect true process conditions. For thermocouples, ensure good thermal contact and proper cold-junction compensation.
-
Power: Supply 5.0 Vdc within the specified range. Verify the power source can deliver the required current (max 50 mA).
Always consult the product manual for detailed wiring diagrams and configuration settings.
Maintenance & Reliability
The FR-T0400K is designed for low-maintenance operation. Periodic checks every 6–12 months are recommended:
-
Inspect connections: Tighten terminal screws and check for corrosion or loose wires.
-
Clean the module: Use dry, oil-free compressed air to remove dust from the housing and vents.
-
Verify accuracy: Compare readings against a calibrated reference to ensure drift remains within specifications.
By following a simple maintenance routine, you extend the module's service life and maintain measurement integrity, contributing to lower total cost of ownership.
Compatibility & Integration
The FR-T0400K is a standalone temperature acquisition module that interfaces with most PLCs, DCS, and PC-based control systems via its analog or digital output signals (refer to the product datasheet for exact output type). It is compatible with a wide range of thermocouples and RTDs, making it a flexible addition to existing setups.
For seamless integration, ensure your controller supports the signal types and measurement ranges provided by the module. The compact size allows for easy placement next to existing I/O modules.
Selection Guide & Purchasing Advice
Before purchasing, verify that the FR-T0400K meets your specific requirements:
-
Sensor compatibility: Confirm your sensor types (thermocouple or RTD) are within the supported list.
-
Measurement range: Ensure the temperature ranges cover your process extremes.
-
Accuracy needs: For high-precision applications, review the accuracy specifications carefully.
-
Power supply: Check that your system can provide 5.0 Vdc with adequate current.
When you are ready to order, PLC Source PRO offers genuine Flexem FR-T0400K modules with fast shipping and reliable customer support. Our team can assist with compatibility questions and ensure you select the right part for your application.
