Product Overview
The Flexem FE7043WE-UL is a 4.3-inch HMI from the 7000 series, engineered for demanding industrial environments. Building on the proven display quality of the 6000 series, it delivers high definition, high brightness, and wide viewing angles. Its upgraded 4-core 1 GHz CPU significantly enhances human-machine interaction, while the integrated IoT function offers a cost-effective, convenient HMI solution for modern automation needs.
Key Benefits
-
Enhanced Performance: The 1 GHz Cortex-A7 quad-core processor ensures rapid response and smooth screen transitions, improving operator efficiency.
-
Built-in IoT: This 4G model comes with integrated IoT capability, enabling remote monitoring and data collection without additional hardware.
-
Robust Design: With an IP65-rated front panel, the FE7043WE-UL withstands dust and water ingress, ensuring reliability in harsh conditions.
-
Wide Power Range: Accepts DC 9V to 28V input, making it adaptable to various industrial power supplies.
-
Compact Footprint: The 138×86×32mm enclosure fits into tight spaces while maintaining a clear 800×480 resolution display.
Technical Specifications
The FE7043WE-UL is built with precision components to meet rigorous industrial standards. Below are the key specifications:
| Parameter |
Value |
| Display |
4.3” 16:9 TFT LCD |
| Resolution |
800 × 480 |
| Brightness |
250 cd/m² |
| Touch Panel |
4-wire industrial resistive touchscreen |
| CPU |
1 GHz, 2-core Cortex-A7 Processor |
| Storage |
128 MB DDR3 + 128 MB Flash |
| Ethernet Port |
1× 10/100 M |
| USB Port |
1× Type-C OTG |
| Rated Power |
< 5 W |
| Rated Voltage |
DC24V, Working range: DC 9 V~28 V |
| Power Protection |
Lightning surge protection |
| Power Interruption Tolerance |
< 5 mS |
| Certification |
CE, RoHS |
| Operating Temperature |
0~50 °C |
| Storage Temperature |
-20~60 °C |
| Environmental Humidity |
10~90% RH (Non-condensing) |
| Vibration Endurance |
10~25 Hz (X,Y,Z direction, 2 G/30 min) |
| Protection Level |
Front: IP65 (NEMA panel), Rear: IP20 |
| Enclosure Material |
Engineering plastic |
| Cutout Size |
132×80 mm |
| Dimensions |
138 × 86 × 32 mm |
| Weight |
About 300 g |
Applications
The FE7043WE-UL excels in a variety of industrial settings. In packaging lines, its high-brightness display ensures clear operator feedback even in bright factory lighting. For machine tool control, the resistive touchscreen allows precise input even with gloved hands. Additionally, its IoT capability makes it ideal for remote monitoring in SCADA systems, enabling centralized data acquisition and control.
Installation & Setup
Mounting the FE7043WE-UL is straightforward. The cutout size is 132×80 mm, and the unit secures with standard panel clamps. Ensure the panel thickness is appropriate for the front IP65 seal. For power, connect a DC supply within the 9V to 28V range, observing correct polarity. Use the Type-C OTG port for program download via USB slave mode or a flash drive. Configure the Ethernet port for network communication, and set up the IoT features through the HMI software.
Maintenance & Reliability
To maximize the lifespan of the FE7043WE-UL, keep the front panel clean and free from abrasive materials. The resistive touchscreen may require recalibration over time; use the built-in calibration utility. Regularly check the power connections for corrosion or looseness. The unit's IP65 front protects against dust and water, but avoid operating in high UV environments as specified. With proper care, the HMI delivers consistent performance for years.
Compatibility & Integration
The FE7043WE-UL integrates seamlessly into existing automation architectures. It supports standard industrial Ethernet (10/100 M) for PLC communication and data exchange. The built-in IoT function allows connection to cloud platforms for remote access. Compatible with major PLC brands via supported drivers, it serves as a versatile operator interface. Always verify driver compatibility with your specific PLC model before deployment.
Buying Guide
When selecting the FE7043WE-UL, confirm your power supply voltage and communication requirements. Ensure the HMI’s cutout size matches your panel. For programming, you will need the corresponding HMI development software. PLC Source PRO offers this genuine Flexem FE7043WE-UL module, backed by quality assurance and reliable support. Contact us for availability and bulk pricing.
