Product Overview
The FANUC A06B-6096-H302 is a high-performance servo amplifier engineered for precision control in industrial CNC applications. This three-axis unit delivers a maximum power rating of 2.4 kW, ensuring reliable operation in demanding machining environments. Whether you are upgrading an existing system or building a new one, the A06B-6096-H302 provides the robust performance your production line requires.
Key Features & Benefits
-
Multi-Axis Control: Supports up to three axes (L, M, N) for versatile CNC configurations.
-
High Power Output: 2.4 kW power rating handles substantial loads with ease.
-
Wide Input Range: Accepts 283–325V input voltage, accommodating varying facility power conditions.
-
Durable Construction: Operates reliably under vibration up to 5G and at altitudes up to 1000 meters above sea level.
-
Thermal Stability: Designed for ambient temperatures from 0°C to 40°C, ensuring consistent performance in typical industrial settings.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Line |
A06B |
| Part Number |
A06B-6096-H302 |
| Product Type |
Servo Amplifier |
| Number of Axes |
3 Axes |
| Power Rating |
2.4 kW |
| Input Voltage |
283–325V |
| Output Voltage |
230V Maximum |
| L-Axis Output Current |
3 Amps |
| M-Axis Output Current |
5.9 Amps |
| N-Axis Output Current |
5.9 Amps |
| Operating Temperature |
0°C to 40°C |
| Maximum Vibration |
5G |
| Maximum Altitude |
1000 Meters Above Sea Level |
| Weight |
22.00 lbs (9.98 kg) |
Industry Applications
The A06B-6096-H302 excels in CNC machining centers, milling machines, and lathes where precise multi-axis motion is critical. Its 2.4 kW power rating ensures adequate torque for heavy cutting operations. For example, a three-axis vertical machining center can rely on the L-axis (3A) for spindle positioning and the M/N axes (5.9A each) for table movement, achieving smooth, accurate contours. This amplifier is equally suited for retrofitting older CNC systems, offering a cost-effective path to improved performance without replacing the entire control cabinet.
Installation & Setup Guidance
When installing the FANUC A06B-6096-H302, ensure the input voltage is within the 283–325V range and that the output connections match the motor specifications. Mount the amplifier in a clean, dry enclosure with adequate ventilation to maintain ambient temperature below 40°C. Secure the unit firmly to minimize vibration exposure, keeping it below the 5G limit. Verify that the axis current ratings (L: 3A, M: 5.9A, N: 5.9A) align with your servo motor requirements before power-up. Proper grounding and shielding of signal cables reduce electrical noise and enhance system stability.
Maintenance & Reliability
Regular inspection of the A06B-6096-H302 helps extend service life and prevent unplanned downtime. Check cooling fans and air filters monthly to ensure unobstructed airflow. Periodically verify that all electrical connections remain tight and free of corrosion. Monitor operating temperatures—if the environment exceeds 40°C, consider supplemental cooling. With proper care, this servo amplifier delivers years of consistent performance, minimizing total cost of ownership.
Selection Guide & Purchasing Advice
Before purchasing, confirm that the A06B-6096-H302 meets your system's voltage, current, and axis count requirements. Verify compatibility with your CNC controller and servo motors. PLC Source PRO offers this genuine FANUC module with fast shipping and responsive support, ensuring you get the right part for your application.
