Product Overview
When servo amplifier failures disrupt production, the FANUC A06B-6096-H106 servo amplifier provides a robust solution for single-axis CNC applications. Designed to withstand vibration up to 5G and operate reliably from 0°C to 40°C, this unit minimizes downtime in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
FANUC |
| Part Number |
A06B-6096-H106 |
| Product Type |
Servo Amplifier |
| Number of Axes |
1 Axis |
| Rated Power |
9.1 kW |
| Output Voltage |
230V |
| Input Voltage |
283-325V |
| Operating Temperature |
0 to 40°C |
| Maximum Vibration |
5G |
| Maximum Altitude |
1000 m |
| Weight |
13.00 lbs (5.90 kg) |
| Dimensions |
11.9 x 14 x 3.3 in |
The FANUC A06B-6096-H106 offers a rated power of 9.1 kW and output voltage of 230V, suitable for driving servo motors in precision motion control. Its input voltage range of 283-325V ensures stable operation even with fluctuating mains. The 5G vibration tolerance and 1000 m altitude rating make it ideal for installations near heavy machinery or at high elevations. The compact dimensions (11.9 x 14 x 3.3 in) and 13.00 lb weight simplify mounting in standard cabinets.
Industry Applications
-
CNC Machining Centers: The single-axis design excels in spindle or axis drives, ensuring accurate positioning and repeatability under load.
-
Robotic Assembly: With 9.1 kW power and 5G vibration resistance, the A06B-6096-H106 handles dynamic movements in pick-and-place and welding robots.
-
Packaging Automation: Reliable 0-40°C operation suits high-speed packaging lines where thermal cycling is common.
Maintenance and Reliability
To maximize lifespan of the FANUC A06B-6096-H106, inspect cooling fans and air filters quarterly. Ensure the ambient temperature stays within 0-40°C to prevent thermal stress. Check cable connections for wear, especially in high-vibration environments. The amplifier's 5G rating reduces the risk of internal component loosening, but periodic torque checks on mounting bolts are recommended. Operating below 1000 m altitude maintains optimal cooling efficiency.
Selection Guide
Before purchasing the FANUC A06B-6096-H106, verify your system's input voltage matches the 283-325V range. Confirm that your motor and controller are compatible with a single-axis servo amplifier rated at 9.1 kW and 230V output. The unit's weight of 13.00 lbs and dimensions (11.9 x 14 x 3.3 in) require a standard cabinet depth of at least 14 inches. For technical support or to confirm compatibility, contact PLC Source PRO (formerly ubest101) for detailed guidance.
