Product Introduction
The FANUC A06B-6096-H105 servo drive is a precision control module designed for demanding CNC applications. As part of the A06B series, this drive delivers reliable performance for motor control in machining centers and automated manufacturing systems. With an output power capacity of 4.75 kW and an input voltage range of 283-325 volts, the A06B-6096-H105 ensures consistent torque and speed regulation, reducing cycle times and improving part quality.
Technical Specifications Breakdown
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Line |
A06B |
| Part Number |
A06B-6096-H105 |
| Product Type |
Servo Drive |
| Output Power |
4.75 kW |
| Input Voltage |
283-325 V |
| Output Voltage |
230 V |
| L-Axis Output Current |
18.7 Amps |
| Operating Temperature |
0 to 40 °C |
| Maximum Vibration |
5G |
| Maximum Altitude |
1000 m |
| Weight |
11.00 lbs (4.99 kg) |
These specifications highlight the FANUC A06B-6096-H105’s ability to handle moderate loads while maintaining high precision. The 18.7A L-axis output current supports sustained torque at low speeds, essential for heavy cutting operations. The wide input voltage tolerance ensures stable operation even in facilities with fluctuating power supplies, minimizing unexpected downtime.
Industry Applications
The FANUC A06B-6096-H105 servo drive excels in CNC milling machines, lathes, and robotic cells. For example, in a 3-axis milling center, this drive controls the spindle axis with high accuracy, reducing scrap rates. Its 5G vibration tolerance makes it suitable for high-speed machining environments where tool chatter could disrupt performance. In retrofit projects, the A06B-6096-H105 replaces older analog drives, providing digital precision and improved energy efficiency—resulting in lower operating costs over the machine’s lifetime.
Maintenance & Reliability
To maximize ROI from the FANUC A06B-6096-H105, follow a preventive maintenance schedule. Inspect the drive’s cooling fan and heat sink quarterly for dust buildup, as overheating reduces component life. Check all power and signal connections annually for tightness. The drive’s ability to function at altitudes up to 1000 meters and in ambient temperatures up to 40°C without derating enhances its reliability in diverse factory settings. Regularly updating firmware (if applicable) ensures compatibility with modern CNC controllers further extends service life.
Selection Guide & Purchasing Advice
Before purchasing the FANUC A06B-6096-H105, verify your existing system’s voltage and current requirements. This drive requires a 283-325V AC input and outputs 230V AC at 18.7A per axis. Ensure your CNC controller supports the drive’s command interface. For replacement applications, confirm that the mounting footprint and connector types match your current installation. PLC Source PRO (ubest101) offers genuine FANUC A06B-6096-H105 drives with fast shipping and technical support to help you integrate this module seamlessly into your automation line.
