Product Overview
When servo amplifier failures disrupt CNC production, the FANUC A06B-6096-H102 servo amplifier provides reliable performance with built-in overload and overcurrent protection. This industrial automation module from FANUC integrates seamlessly into CNC systems, ensuring precise motion control and minimal downtime.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Type |
Servo Amplifier (Servo Drive) |
| Part Number |
A06B-6096-H102 |
| Weight |
11.00 lbs (4.99 kg) |
| Interface Type |
FSSB Interface |
| Cooling Method |
Air Cooled |
| Frequency |
50/60 Hz |
| Servo Unit Type |
ALPHA SERVO DRIVE MODEL SVM1-20 |
| Protection Features |
Overload, Overcurrent Protection |
| Mounting |
Vertical/Wall-mounted |
| Operating Temperature |
0°C to 55°C |
Application Scenarios
The FANUC A06B-6096-H102 servo amplifier excels in CNC machining centers, lathes, and milling machines. It ensures precise spindle and axis control, reducing scrap and improving cycle times. Its FSSB interface enables fast communication within multi-axis systems, making it suitable for high-speed production environments.
Installation & Setup Guidance
Install the FANUC A06B-6096-H102 in a vertical or wall-mounted orientation to conserve space. Ensure adequate airflow around the air-cooled unit to prevent overheating. Secure the mounting bracket firmly and connect the FSSB cable per the system diagram. Verify the input power matches the 50/60 Hz requirement before energizing.
Maintenance & Reliability
Regularly inspect the cooling fins of the FANUC A06B-6096-H102 for dust buildup and clean with compressed air. Check connections for tightness to avoid intermittent faults. The overload and overcurrent protection extend the amplifier's life, reducing total cost of ownership. Operate within the 0°C to 55°C range for optimal reliability.
For selection guidance, contact ubest101 to confirm compatibility with your CNC system and ensure the correct ALPHA SERVO DRIVE MODEL SVM1-20 configuration.
