Product Introduction
When CNC systems experience servo drive failures, the FANUC A06B-6093-H113 provides robust overload and overcurrent protection to minimize downtime. This servo amplifier, part of the A06B product line, is designed for integration into CNC systems, offering dependable performance under specified operational conditions. The A06B-6093-H113 is engineered as a BETA SERVO UNIT TYPE SVU-40, delivering precise control for demanding applications.
Technical Specifications Breakdown
The FANUC A06B-6093-H113 features a rated output current of 12.5 A, ensuring sufficient power for various CNC servo motors. It operates on an input voltage of 220-240 VAC at 50/60 Hz, adapting to global power standards. The unit weighs 7.00 lbs (3.18 kg) and supports vertical or wall-mounted configurations, saving valuable cabinet space. Cooling is managed via forced air (air cooled), with an operating temperature range of 0°C to 55°C. Protection features include overload and overcurrent protection, safeguarding both the amplifier and connected systems.
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Type |
Servo Amplifier (Servo Drive) |
| Part Number |
A06B-6093-H113 |
| Rated Output Current |
12.5 A |
| Input Voltage |
220-240 VAC |
| Frequency |
50/60 Hz |
| Weight |
7.00 lbs (3.18 kg) |
| Interface Type |
FSSB Interface |
| Cooling Method |
Air Cooled |
| Mounting |
Vertical/Wall-mounted |
| Operating Temperature |
0°C to 55°C |
| Protection Features |
Overload, Overcurrent Protection |
| Servo Unit Type |
BETA SERVO UNIT TYPE SVU-40 |
| Application |
CNC Systems |
Industry Applications
The FANUC A06B-6093-H113 is primarily used in CNC machine tools, such as milling, turning, and machining centers. In high-precision manufacturing, the 12.5 A output and FSSB interface ensure smooth communication with the CNC controller. For example, in a vertical machining center, this servo amplifier drives the axis motors with reliable torque and speed control, reducing cycle times and improving surface finish. The overload protection feature is especially valuable in applications with sudden load changes, preventing drive damage and unplanned downtime.
Maintenance & Reliability
To maintain reliable performance of the FANUC A06B-6093-H113, ensure the air cooling vents are kept clean and unobstructed. The operating temperature range of 0°C to 55°C should be respected; install the unit in a well-ventilated cabinet to avoid thermal stress. Regular inspection of terminal connections and adherence to the vertical mounting orientation will prolong service life. The built-in overload and overcurrent protection features reduce the risk of failure, but periodic checks of the supply voltage (220-240 VAC) are recommended to ensure optimal performance.
Compatibility & Integration
The FANUC A06B-6093-H113 uses the FSSB (Fanuc Serial Servo Bus) interface for high-speed communication with compatible CNC controllers, such as the FANUC Series 0i and 30i. It integrates seamlessly into existing CNC systems, supporting both analog and digital servo signals. The unit is designed for use with FANUC servo motors and is part of the BETA servo series, ensuring plug-and-play compatibility with other SVU-40 components. Before integration, verify the controller firmware supports the FSSB protocol.
Selection Guide & Purchasing Advice
When selecting the FANUC A06B-6093-H113, verify your CNC system’s voltage and frequency requirements (220-240 VAC, 50/60 Hz). Ensure the servo motor’s current rating does not exceed 12.5 A. For assistance with compatibility or to confirm the exact revision, contact PLC Source PRO (available at ubest101.myshopify.com) for expert guidance and genuine spare parts.
