Product Introduction
When CNC servo systems face demanding loads and harsh industrial environments, the FANUC A06B-6090-H006 servo amplifier delivers precision control and robust reliability. Designed specifically for CNC systems, this unit is a critical component for driving servo motors with agility and efficiency. The A06B-6090-H006 integrates overload, overcurrent, and overvoltage protection to safeguard against common failure modes, making it a trusted choice for automation professionals.
Key Technical Specifications
The FANUC A06B-6090-H006 offers a rated output current of 80 A and operates on input voltage from 200 to 230 VAC at 50/60 Hz. It provides an output voltage of 230 VAC, ensuring compatibility with standard servo motors. With an operating temperature range of 0°C to 55°C and air-cooled design, it maintains performance in diverse conditions. The unit weighs 11.00 lbs (4.99 kg) and supports vertical or wall-mounted installation.
| Specification |
Value |
| Manufacturer |
FANUC |
| Product Type |
Servo Amplifier (Servo Drive) |
| Product Line |
A06B |
| Part Number |
A06B-6090-H006 |
| Weight |
11.00 lbs (4.99 kg) |
| Application |
CNC Systems |
| Protection Features |
Overload, Overcurrent, Overvoltage |
| Mounting |
Vertical/Wall-mounted |
| Rated Output Current |
80 A |
| Operating Temperature |
0°C to 55°C |
| Cooling Method |
Air Cooled |
| Input Voltage |
200-230 VAC |
| Frequency |
50/60 Hz |
| Output Voltage |
230 VAC |
Industrial Applications
The FANUC A06B-6090-H006 excels in CNC machining centers, lathes, and milling machines where precise servo control is vital. Its 80 A output handles medium to high torque servo motors, ensuring smooth acceleration and deceleration under heavy loads. The built-in protection features reduce downtime caused by electrical faults, directly addressing common failure scenarios in production environments.
Maintenance & Reliability
Regular inspection of the air cooling vents and electrical connections ensures long-term reliability of the A06B-6090-H006. The unit's robust protection against overload and overvoltage minimizes wear on internal components, extending service life. Operating within the 0°C to 55°C range and ensuring proper airflow will prevent thermal stress. By following these simple practices, industrial users can maximize uptime and reduce total cost of ownership.
Selection Guide & Purchasing Advice
Before purchasing the FANUC A06B-6090-H006, verify that your CNC system requires a servo amplifier with 80 A output and 200-230 VAC input. Ensure adequate ventilation for air cooling and available mounting space for vertical or wall installation. As a trusted supplier, PLC Source PRO offers this model with detailed support. Check compatibility with your servo motor specifications to guarantee optimal performance.
