Product Overview
When CNC systems require precise motor control, the FANUC A06B-6090-H004 Servo Amplifier delivers reliable performance. This unit is designed for high-accuracy positioning and speed regulation. With a rated output current of 40 A, it handles demanding machining tasks. Part of the FANUC A06B series, the A06B-6090-H004 is an essential upgrade or replacement for older servo drives.
Technical Specifications
The FANUC A06B-6090-H004 operates with an input voltage of 200-230 VAC and delivers a steady 230 VAC output. It supports frequencies of 50/60 Hz, making it adaptable to global electrical systems. The air-cooled design ensures thermal management without complex plumbing. Weighing 11.00 lbs (4.99 kg), it is compact enough for vertical or wall-mounted installations. Protection features include overload, overcurrent, and overvoltage safeguards.
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Type |
Servo Amplifier (Servo Drive) |
| Part Number |
A06B-6090-H004 |
| Weight |
11.00 lbs (4.99 kg) |
| Rated Output Current |
40 A |
| Application |
CNC Systems |
| Cooling Method |
Air Cooled |
| Frequency |
50/60 Hz |
| Input Voltage |
200-230 VAC |
| Output Voltage |
230 VAC |
| Protection Features |
Overload, Overcurrent, Overvoltage |
| Mounting |
Vertical/Wall-mounted |
| Operating Temperature |
0°C to 55°C |
Industry Applications
The FANUC A06B-6090-H004 excels in CNC machining centers, robotic arms, and automated assembly lines. In a typical milling machine upgrade, this servo amplifier replaces older units to improve positioning accuracy and reduce downtime. For high-speed spindle control, its 40 A output provides ample current. The 50/60 Hz frequency compatibility allows integration into both European and North American facilities.
Installation & Setup Guidance
Mount the FANUC A06B-6090-H004 vertically or on a wall in a well-ventilated area. Ensure the input power supply matches 200-230 VAC and the frequency is either 50 or 60 Hz. Use proper gauge wiring for the 40 A rated output current. Connect to the CNC controller per the manufacturer's wiring diagram. Verify that the protective features (overload, overcurrent, overvoltage) are correctly connected to the safety circuit.
Selection Guide & Purchasing Advice
Before purchasing the FANUC A06B-6090-H004, confirm your existing system voltage and current requirements. This unit is ideal for replacing older FANUC series A or B servo amplifiers. If you need a spare for your CNC system, visit PLC Source PRO (ubest101.myshopify.com) for genuine parts. Check compatibility with your specific CNC control model to ensure a smooth upgrade.
