Product Introduction
When CNC servo systems suffer from outdated amplifiers causing position inaccuracies or frequent faults, the FANUC A06B-6079-H301 provides a robust upgrade path. This servo amplifier (servo drive) is engineered for triple-axis configurations within CNC systems, delivering reliable control of position, speed, and torque. As part of the A06B product line, the A06B-6079-H301 integrates protection mechanisms against overload, overcurrent, and overvoltage, ensuring operational safety even under demanding conditions.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Type |
Servo Amplifier (Servo Drive) |
| Product Line |
A06B |
| Part Number |
A06B-6079-H301 |
| Weight |
15.00 lbs (6.80 kg) |
| Cooling Method |
Air Cooled |
| Rated Input Voltage |
283-325 V |
| Maximum Output Voltage |
230 V |
| Rated Power |
1.85 kW |
| Frequency |
50/60 Hz |
| Control Type |
Position, Speed, and Torque Control |
| Operating Temperature |
0°C to 55°C |
| Axis |
Triple Axis Drive |
| Application |
CNC Systems |
| Protection Features |
Overload, Overcurrent, Overvoltage Protection |
| Mounting |
Vertical/Wall-mounted |
Industry Applications
The FANUC A06B-6079-H301 is ideal for CNC machining centers, milling machines, and lathes that require precise coordinated motion across three axes. Its 1.85 kW rated power and 230 V maximum output voltage handle demanding cutting and positioning tasks. The triple-axis drive reduces wiring complexity and cabinet space, making it a preferred upgrade for older single-axis systems.
Troubleshooting & Common Issues
Common failures in servo amplifiers include overheating, current spikes, and voltage surges. The A06B-6079-H301 addresses these with integrated overload, overcurrent, and overvoltage protection. Its air-cooled design maintains safe operating temperatures within the specified 0°C to 55°C range. For stable operation, ensure the input voltage stays within 283-325 V and that the mounting orientation allows adequate airflow.
Maintenance & Reliability
Routine inspection of cooling fins and connectors keeps the FANUC A06B-6079-H301 running reliably. The unit's vertical or wall-mounted installation simplifies access. Regularly monitor ambient temperature to stay within the 0°C to 55°C limit. With proper care, this servo amplifier delivers long service life in continuous CNC operations.
Selection Guide
When selecting the FANUC A06B-6079-H301, verify compatibility with your CNC controller and motor feedback systems. The unit supports position, speed, and torque control, making it flexible for various applications. For genuine, tested units, consider purchasing from a trusted supplier like PLC Source PRO (available at ubest101). Always confirm the part number A06B-6079-H301 matches your requirements before ordering.
