Product Introduction
When CNC systems require precise and reliable motion control, the FANUC A06B-6079-H201 dual-axis servo amplifier delivers exceptional performance. This unit handles position, speed, and torque control within a frequency range of 50 to 60 Hz, ensuring compatibility with diverse industrial setups. The FANUC A06B-6079-H201 is an air-cooled servo drive designed for demanding CNC applications.
Technical Specifications Breakdown
Below are the key technical parameters for the FANUC A06B-6079-H201. Each specification contributes to the reliability and efficiency of this servo amplifier.
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Type |
Servo Amplifier (Servo Drive) |
| Part Number |
A06B-6079-H201 |
| Weight |
15.00 lbs (6.80 kg) |
| Frequency |
50/60 Hz |
| Cooling Method |
Air Cooled |
| Protection Features |
Overload, Overcurrent, Overvoltage Protection |
| Application |
CNC Systems |
| Mounting |
Vertical/Wall-mounted |
| Control Type |
Position, Speed, and Torque Control |
| Operating Temperature |
0°C to 55°C |
| Axis |
Dual axis drive |
The dual-axis design of the FANUC A06B-6079-H201 allows it to control two motors simultaneously, reducing system complexity. Its air-cooled construction ensures thermal stability even under continuous operation. The integrated protection features—overload, overcurrent, and overvoltage—safeguard both the drive and connected equipment, addressing common failure modes in servo systems.
Industry Applications
The FANUC A06B-6079-H201 finds use in a variety of CNC machining centers, milling machines, and lathes. In a typical milling application, the dual-axis servo amplifier controls the X and Y axes simultaneously, providing coordinated motion for precise contouring. The built-in protection prevents damage from sudden current spikes or mechanical overloads, which are frequent issues in high-production environments. Additionally, the 50/60 Hz frequency support makes the FANUC A06B-6079-H201 suitable for global installations.
Installation & Setup Guidance
Mount the FANUC A06B-6079-H201 vertically or on a wall using the provided brackets. Ensure adequate airflow around the air-cooled heatsink to maintain the specified operating temperature range of 0°C to 55°C. Connect the DC bus and motor power cables according to the wiring diagram provided in the manual. Use proper grounding techniques to minimize electrical noise. The dual-axis configuration requires careful phase matching for each motor.
Maintenance & Reliability
Regular maintenance for the FANUC A06B-6079-H201 includes inspecting cooling fans for dust accumulation and checking connections for signs of overheating. Since the drive includes overload and overvoltage protection, most electrical faults are managed automatically. However, periodic testing of the protection circuitry is recommended to ensure continued reliability. The air-cooled design reduces the need for frequent servicing, contributing to lower total cost of ownership.
Selection Guide & Purchasing Advice
Before purchasing the FANUC A06B-6079-H201, verify that your CNC system's voltage and current ratings match the drive's specifications. Ensure the mounting orientation allows for proper ventilation. For system integration, you may need appropriate cables and a matching power supply. As a reliable supplier, PLC Source PRO offers genuine FANUC A06B-6079-H201 modules with fast shipping. Visit ubest101.myshopify.com for more details.
