Product Introduction
When industrial operations demand robust and reliable motion control, the FANUC A06B-0186-B675 delivers exceptional performance. This high-performance motor from the A06B series is engineered for demanding environments, providing consistent torque and speed across various automation tasks. With a rated power of 3.8 kW and maximum torque of 30 Nm, the FANUC A06B-0186-B675 handles heavy loads and rapid acceleration with ease. Its 3-phase design and IP67 protection ensure reliable operation even in harsh conditions, minimizing downtime and maintenance costs.
Technical Specifications
The following table summarizes key performance and physical parameters of the FANUC A06B-0186-B675, as provided by the manufacturer:
| Parameter |
Value |
| Manufacturer |
FANUC |
| Part Number |
A06B-0186-B675 |
| Rated Power |
3.8 kW |
| Rated Torque |
30 Nm |
| Rated Speed |
2000 RPM |
| Voltage |
228 V |
| Frequency |
133 Hz |
| Current |
9.8 A |
| Phase Type |
3-Phase |
| Encoder Type |
A64 |
| Shaft Type |
Tapered |
| Brake Included |
Yes |
| Insulation Class |
F |
| Protection Class |
IP67 |
| Cooling Type |
Air-cooled |
| Mounting Type |
Flange mounting (IM B5) |
| Weight |
77.00 lbs (34.93 kg) |
These specifications make the FANUC A06B-0186-B675 a versatile choice for applications requiring precise motion control and durability.
Industry Applications
The FANUC A06B-0186-B675 excels in material handling, packaging, and machine tool applications where high torque and IP67 protection are essential. For example, in a robotic palletizer, the motor's 30 Nm torque ensures smooth lifting of heavy loads, while the integrated brake provides safe holding during power loss. Its air-cooled design and tapered shaft allow easy coupling to gearboxes or pulleys, reducing installation complexity. In a CNC machining center, the 3.8 kW power and 2000 RPM speed deliver precise spindle or axis motion, enhancing productivity.
Installation & Setup
Mounting the FANUC A06B-0186-B675 is straightforward using the flange IM B5 configuration. Ensure the mounting surface is flat and rigid to avoid vibration. For electrical connections, use a 3-phase supply compatible with 228 V and 133 Hz. The A64 encoder requires careful wiring to maintain signal integrity. The tapered shaft accepts standard coupling hubs; verify keyway dimensions to avoid slippage. Always follow the manufacturer's torque specifications for bolts. The motor weight of 77 lbs may require lifting assistance.
Maintenance & Reliability
The FANUC A06B-0186-B675 is built for long service life with Class F insulation and IP67 sealing. Regularly inspect the air-cooling vents for dust buildup. The brake mechanism should be tested monthly to ensure proper operation. Bearing condition should be checked annually via vibration analysis. Operating within rated current (9.8 A) and voltage (228 V) prevents overheating. With proper care, this motor reduces total cost of ownership by minimizing unplanned downtime.
Selection Guide & Purchasing Advice
Before purchasing the FANUC A06B-0186-B675, verify that your system's electrical supply matches the motor's 3-phase, 228 V, 133 Hz requirements. Confirm that the encoder output (A64) is compatible with your controller. Consider ambient conditions: IP67 allows outdoor use but ensure cooling air is unobstructed. For a reliable source, ubest101 stocks genuine FANUC A06B-0186-B675 units with fast shipping. Always purchase from an authorized distributor to guarantee authenticity and warranty support.
