Product Overview
With an efficiency rating of 0.98 and low power consumption, the FANUC A02B-0307-B822 Machine Control Unit delivers significant operational cost savings. This rack-mountable unit operates on a 24 V DC input and integrates RS-232 and Ethernet interfaces for flexible connectivity. Designed as a basic 2-slot unit, it is ideal for space-constrained industrial environments where reliable machine control is essential.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
FANUC (A02B-0307-B822) |
| Product Type |
Machine Control Unit |
| Part Number |
A02B-0307-B822 |
| Input Voltage |
24 V DC |
| Communication Interface |
RS-232 / Ethernet |
| Unit Spec |
Basic 2 Slot Unit |
| Operating Temperature |
0-55°C |
| Mounting Type |
Rack-Mountable |
| Protection Rating |
IP20 |
| Power Consumption |
Low |
| Efficiency |
0.98 |
| Weight |
1.25 lbs (0.57 kg) |
| Length |
14 inches |
| Width |
6 3/4 inches |
Industry Applications
In manufacturing cells where precise machine control is critical, the FANUC A02B-0307-B822 provides reliable operation with minimal energy usage. Its compact form factor and 0.98 efficiency translate to reduced electricity costs over time. Common applications include CNC machining, robotic workstations, and automated assembly lines. The unit's low power consumption makes it an excellent choice for systems requiring continuous uptime while keeping operational expenses low.
Installation & Setup Guidance
Mount the A02B-0307-B822 in a standard 19-inch rack. Ensure the supply voltage is stable 24 V DC. Connect RS-232 and Ethernet cables per system wiring diagram. The IP20 rating requires installation in a clean, dry enclosure. No calibration is needed beyond basic configuration. Verify that the rack location allows adequate airflow for the 0-55°C operating range.
Compatibility & Integration
The FANUC A02B-0307-B822 integrates seamlessly with other FANUC controllers and automation systems via its RS-232 and Ethernet ports. It can be networked for remote monitoring and data exchange, supporting standard industrial protocols over Ethernet. This flexibility enables easy integration into existing control architectures, reducing downtime during upgrades.
Selection Guide & Purchasing Advice
When selecting the A02B-0307-B822, verify that your system requires a 24 V DC supply and a basic 2-slot unit. Ensure rack space accommodates the 14-inch length and 6.75-inch width. As a trusted supplier, PLC Source PRO (via ubest101) offers genuine FANUC modules with fast shipping. Contact our team for compatibility assistance with your specific application.
