Introduction to the FANUC A02B-0281-C081
The FANUC A02B-0281-C081 is a high-performance 10.4-inch color LCD display monitor designed for industrial automation environments. This display integrates a capacitive touch panel, enabling intuitive operator interaction and precise control. With a resolution of 800 x 600 pixels and a brightness of 300 cd/m², the FANUC A02B-0281-C081 delivers clear, detailed visuals that are essential for monitoring and control tasks in factory floors, process plants, and machine tool applications.
Technical Specifications
| Specification |
Value |
| Manufacturer |
FANUC |
| Product Type |
Display Monitor |
| Display Size |
10.4" LCD |
| Display Type |
Color LCD with Graphic & Touch Panel |
| Touch Panel |
Capacitive Touch Panel |
| Resolution |
800 x 600 pixels |
| Brightness |
300 cd/m² |
| Operating Temperature |
0°C to 50°C |
| Input Voltage |
100-240 VAC |
| Weight |
4.75 lbs (2.15 kg) |
| Mounting Type |
Panel Mount |
Real-World Applications
The FANUC A02B-0281-C081 serves as a primary HMI interface in CNC machine tools, robotic workcells, and assembly line monitoring stations. Its capacitive touch panel responds accurately even with gloved hands, making it suitable for automotive and heavy manufacturing environments. In food processing plants, the monitor's 300 cd/m² brightness ensures readability under varying ambient light conditions. Upgrading from older monochrome or resistive touch displays to this FANUC A02B-0281-C081 model reduces operator fatigue and improves productivity through sharper graphics and faster touch response.
Installation & Setup Guidance
Mount the FANUC A02B-0281-C081 into a standard panel cutout using the provided panel mount brackets. Ensure the mounting surface is clean and free of vibrations. Connect the power supply to a 100-240 VAC source using appropriate gauge wiring. The capacitive touch panel requires a clean, dry surface for optimal accuracy; avoid applying excessive pressure during setup. For best performance, position the display at eye level within the operator's reach.
Maintenance & Reliability
Regularly inspect the FANUC A02B-0281-C081 for dust accumulation on the screen and cooling vents. Clean the capacitive touch panel with a soft, lint-free cloth and a mild cleaning solution. Verify that the ambient temperature stays within the 0°C to 50°C operating range to prevent thermal stress. The robust solid-state design requires minimal periodic maintenance, offering long-term reliability in continuous industrial use. Proper maintenance extends the service life and lowers total cost of ownership.
Selection Guide & Purchasing Advice
Before purchasing a FANUC A02B-0281-C081, verify that your system supports a 10.4-inch panel mount display with VGA or DVI input (based on your existing controller). Confirm that the mounting cutout dimensions match the panel mount specification. For assistance in selecting the right display for your application, contact ubest101, a trusted supplier of industrial automation parts. Ensure you have the necessary cables and adapters for integration with your FANUC or third-party control system.
