Product Overview
Upgrade your industrial HMI with the FANUC A02B-0281-C071 10.4-inch color LCD display monitor. Designed specifically for demanding factory floor environments, this panel-mount unit replaces older monochrome or smaller displays with crisp 800x600 pixel resolution and soft-key graphic support. Whether you are modernizing a CNC machine or retrofitting a production line, the A02B-0281-C071 delivers clear visual feedback for precise operator control.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
FANUC |
| Part Number |
A02B-0281-C071 |
| Product Type |
Display Monitor |
| Display Size |
10.4" LCD |
| Resolution |
800 x 600 pixels |
| Display Type |
Color LCD with Graphic & Soft Keys |
| Brightness |
300 cd/m² |
| Response Time |
8 ms |
| Input Voltage |
100-240 VAC |
| Mounting Type |
Panel Mount |
| Operating Temperature |
0°C to 55°C |
| Weight |
6.25 lbs (2.83 kg) |
These specifications ensure reliable operation in a wide range of industrial environments. The 300 cd/m² brightness and 8 ms response time guarantee clear, real-time display of machine status and alarms.
Real-World Applications
-
CNC Machine Control: Connect the FANUC A02B-0281-C071 directly to a FANUC controller for operator panel integration. The soft keys simplify menu navigation and parameter entry.
-
Production Line HMI: Replace worn-out displays in assembly or packaging machines. The 10.4-inch size fits standard panel cutouts, and the wide voltage range (100-240 VAC) suits global installations.
-
Process Monitoring: Use in SCADA systems where a dedicated local display is needed. The color LCD with graphic support presents trends and alarms clearly.
Installation & Setup Guidance
Mount the A02B-0281-C071 into a standard panel cutout using the provided hardware. Ensure the ambient temperature stays within 0°C to 55°C. Connect the 100-240 VAC power supply to the designated input terminals. The display accepts standard video inputs from FANUC controllers; refer to your system manual for cable pinouts. After mounting, power on and verify the startup screen appears. Adjust brightness using the on-screen menu if needed.
Selection Guide & Purchasing Advice
Before purchasing, confirm that the mounting cutout matches a 10.4-inch LCD panel. Also verify that your controller supports the video output format used by this unit. For a reliable replacement or upgrade, source the FANUC A02B-0281-C071 from a trusted supplier. PLC Source PRO (visit ubest101.myshopify.com) stocks this exact model and offers fast shipping for industrial automation spares.
