Introduction
The FANUC A02B-0118-B003 Power Mate Control is a dedicated controller designed as a drop-in upgrade for CNC machines requiring enhanced communication and control. This module enables seamless integration with DPL, MDI, and I/O ports, making it ideal for replacing legacy controls. With dual communication interfaces and a 1.5 MHz transmission rate, the A02B-0118-B003 ensures reliable data exchange in demanding industrial environments.
Technical Specifications
| Specification |
Value |
| Manufacturer |
FANUC |
| Product Line |
A02B |
| Part Number |
A02B-0118-B003 |
| Weight |
11.00 lbs (4.99 kg) |
| Communication Interfaces |
2 |
| Transmission Rate |
1.5 MHz |
| Ports |
DPL, MDI, and I/O |
| Ambient Temperature Range |
0 to 40 °C |
| Operating Humidity |
Up to 80% (non-condensing) |
| Storage Humidity |
Up to 80% (non-condensing) |
| Maximum Altitude |
1000 meters without derating |
Industry Applications
The FANUC A02B-0118-B003 excels in CNC machining centers, lathes, and milling machines. Its dual communication interfaces allow for simultaneous connection to operator panels and remote I/O modules. For example, in a high-volume production line, replacing an older control with the A02B-0118-B003 reduces data latency and improves machine uptime. The 1.5 MHz transmission rate supports fast tool changes and precise axis coordination.
Maintenance and Reliability
Regular inspection of the FANUC A02B-0118-B003 ensures long service life. Operating within 0–40 °C and humidity up to 80% (non-condensing) prevents condensation damage. The unit’s robust design tolerates altitudes up to 1000 meters without performance derating. Clean the ports periodically to maintain signal integrity. With proper care, this module provides years of reliable control for your CNC equipment.
Selection Guide
Before purchasing the FANUC A02B-0118-B003, verify compatibility with your CNC machine’s existing wiring and I/O requirements. Ensure the DPL, MDI, and I/O port mappings match your system. For a reliable supply, consider PLC Source PRO (previously ubest101) — a trusted distributor of industrial automation spares. Check the weight of 4.99 kg for shipping logistics.
