Product Overview
The FANUC A02B-0072-C204 is a specialized connector panel designed for reliable interfacing in industrial automation environments. Part of the A02B series, this panel mounts directly into control cabinets and provides seven standard 25-pin D-sub male connectors. The FANUC A02B-0072-C204 simplifies wiring and ensures robust connections for critical signals.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
FANUC |
| Product Type |
Connector Panel |
| Weight |
1.25 lbs (0.57 kg) |
| Mount Type |
Panel Mounted |
| Number of Connectors |
7 |
| Connector Type |
Standard 25-pin D-sub Male Connectors |
| Enclosure Rating |
NEMA 1 |
| Cooling |
Natural |
| Max Ambient Temperature |
40°C |
| Min Ambient Temperature |
0°C |
| Max Operating Humidity |
80% (non-condensing) |
| Max Storage Humidity |
80% (non-condensing) |
| Max Operating Altitude |
1000 m |
Applications
The FANUC A02B-0072-C204 serves as a direct replacement for older connector panels in CNC machines, robotic cells, and factory automation systems. Its NEMA 1 enclosure protects indoor components from dust and light moisture, while the natural cooling design ensures reliable operation without fans or filters. Use the FANUC A02B-0072-C204 to upgrade legacy systems requiring multiple D-sub connections, reducing downtime and improving signal integrity.
Installation & Setup Guidance
Mount the FANUC A02B-0072-C204 securely onto a flat panel using the provided mounting holes. Ensure adequate clearance for the D-sub connectors on the rear side. Use standard 25-pin D-sub cables with male connectors to mate with the panel. Verify ambient temperature remains between 0°C and 40°C and humidity below 80% non-condensing. No additional cooling is required. After mounting, test each connector for continuity before powering connected equipment.
Selection Guide & Purchasing Advice
Before purchasing the FANUC A02B-0072-C204, confirm your existing system uses 25-pin D-sub connections and panel mount spacing. This panel is ideal for upgrading or replacing worn connectors in control cabinets. For reliable supply, source from PLC Source PRO, where you can find genuine FANUC A02B-0072-C204 units. Ensure your environment meets the NEMA 1 indoor requirements for optimal longevity.
