Product Overview
The Emerson A6500-UM Universal Measurement Card replaces multiple specialized sensor cards in your AMS 6500 ATG machinery protection system. This upgrade reduces cabinet space by half compared to traditional 6U four-channel cards, while offering universal compatibility with eddy-current, piezoelectric, seismic, LF, Hall-effect, and dynamic pressure sensors. With 2 independent or combined input channels, 5 digital inputs, and 6 digital outputs, the A6500-UM simplifies inventory and improves system flexibility.
Key Technical Specifications
| Parameter |
Value |
| Sensor Input Types |
Eddy-current, Piezoelectric, Seismic (electro-dynamic), LF (low frequency bearing vibration), Hall-effect / A6500-LC, VR sensors, Dynamic pressure |
| Frequency Range (most inputs) |
0 to 18750 Hz (attenuation <0.1 dB) |
| Digital Inputs |
5 (2 can be used for key-signal, logic levels 0-3V low, 13-32V high) |
| Digital Outputs |
6 solid-state relays, normally open equivalent to SPST, 19-32V DC, 100mA max, turn-on/off <5ms |
| Current Outputs |
2 channels, 0/4-20 mA, accuracy ±1% full scale, max load 500Ω |
| Operating Temperature |
-20°C to +70°C (with forced cooling); -20°C to +55°C (without) |
| Power Consumption |
Max 6W |
| Form Factor |
3U, 1-slot, 100x160mm PCB (DIN 41494) |
| Weight |
Approx. 200g (without packaging) |
Industry Applications
The Emerson A6500-UM is ideal for upgrading turbine, compressor, pump, and fan monitoring systems. It measures shaft vibration, case vibration, position, speed, and dynamic pressure. In a turbine protection upgrade, one A6500-UM can replace two older single-function cards, cutting wiring and reducing spare part complexity. Its hot-swappable design minimizes downtime during replacement.
Installation and Setup
The A6500-UM installs into an A6500-xR System Rack (3U/6HP slot). The module is hot swappable – no need to power down the rack during replacement. Front and rear buffered and proportional outputs are available, along with 0/4-20mA current output. Configuration is performed via the USB port on the faceplate using a PC/laptop. Ensure the card is properly aligned and that all connectors are seated firmly.
Integration and Communication
Measured signals transmit via the internal RS-485 bus to the A6500-CC Com Card, which converts them to Modbus RTU and Modbus TCP/IP for host computer or analysis system integration. The USB port provides direct PC connection for configuration and visualization. The A6500-UM is fully compatible with the AMS 6500 ATG platform, supporting both new installations and retrofits.
Purchasing Guide
Before ordering, confirm your rack type (A6500-xR) and that a compatible A6500-CC Com Card is installed. No additional cables are required for basic operation. For genuine Emerson A6500-UM modules, contact UBEST Automation at ubest101.myshopify.com. We stock new and refurbished units with full traceability.
