Product Overview
When your monitoring system needs reliable alarm and trip outputs, the Bently Nevada 3500/33-01-00 149992-01 16-Channel Relay Module delivers. This module provides 16 independent relay channels in a compact 1-slot package, making it a vital component for machinery protection and condition monitoring in industrial environments.
Manufactured in the U.S.A., the 3500/33-01-00 149992-01 is part of the proven 3500 series, designed for seamless integration into existing 3500 racks. With its epoxy-sealed relays and arc suppressors, it ensures dependable performance even in demanding conditions.
Key Specifications
The 3500/33-01-00 149992-01 is engineered for flexibility and precision. Below are the critical parameters that define its operation:
-
Relay Type: Single-pole double-throw (SPDT)
-
Relay Contact Life: 10,000 cycles
-
Relay Operation: Four groups of four channels switch-selectable for Normally De-energized (ND) or Normally Energized (NE) operation
-
Power Consumption: 5.8 watts typical
-
Operating Temperature: -30 °C to +65 °C (-22 °F to +150 °F)
-
Storage Temperature: -40 °C to +85 °C (-40 °F to +185 °F)
-
Humidity: 95%, non-condensing
Relay Contact Ratings
The relay contacts are rated for various load conditions, ensuring compatibility with different system requirements.
Standard Systems
-
Min Switched Current: 100 mA @ 5 Vdc
-
Max Switched Current: 5 A
-
Max Switched Power (DC): 70 W @ 24 Vdc, 10 W @ 48 Vdc, 9 W @ 60 Vdc
-
Max Switched Voltage (DC): 125 Vdc
-
Max Switched Power (AC): 1200 VA
-
Max Switched Voltage (AC): 250 Vac
Failsafe and Hazardous Area Systems
-
Min Switched Current: 100 mA @ 5 Vdc (standard silver contacts)
-
Max Switched Current: 5 A
-
Max Switched Voltage (DC): 30 Vdc
-
Low Current (gold-plated) contacts: Min 1 mA @ 1 Vdc
Special Low Current Relay Applications
-
DC Specifications: Min Switched Current 1 mA @ 1 Vdc, Max Switched Current 100 mA @ 48 Vdc
-
AC up to 120VAC: Minimum switching current for gold-plated contacts is 1 mA; maximum switching current before damaging gold relays is 5 mA
Physical and Installation
The module’s compact design fits into one full-height front slot in the 3500 rack.
-
Dimensions (H x W x D): 241 mm x 24.4 mm x 242 mm (9.50 in x 0.96 in x 9.52 in)
-
Weight: 0.7 kg (1.6 lb)
-
Rack Space: 1 full-height front slot
Compatibility and Software Requirements
Ensure your system meets the following requirements for proper operation:
- Requires 3500 Rack Config version 3.3 or later
- Requires 3500 Data Acquisition Software version 2.40 or later
- Requires 3500 Data Display Software version 1.40 or later
When ordered with the multiple approvals option (-02), the module is certified to Zone 2 standards, including ATEX and North American zones. However, note that the 3500/33-01-00 149992-01 does not meet increased spacing requirements at higher voltages, so the voltage is limited. For CSA-only approvals (-01), the voltage is de-rated to 30 Vrms to comply with 61010-1 type test requirements. If used in functional safety (SIL) systems, the restricted voltage must be followed; higher voltages are not allowed.
Applications
The 3500/33-01-00 149992-01 is ideal for machinery protection systems, vibration monitoring, and critical asset protection in industries such as power generation, oil and gas, and manufacturing. Its relay outputs can drive alarm annunciators, shutdown systems, or PLC inputs, providing a robust interface between the monitoring system and plant control.
Maintenance and Reliability
With a relay contact life of 10,000 cycles, the 3500/33-01-00 149992-01 offers long-term reliability. The epoxy-sealed relays protect against environmental contaminants, while the built-in arc suppressor (250 Vrms) extends contact life. Regular inspection of relay operation and system functionality is recommended to ensure continuous protection.
Selection Guide
Before ordering, verify your rack configuration and software versions to ensure compatibility. Consider the approvals option that matches your area classification. For expert assistance and competitive pricing, PLC Source PRO is your trusted supplier for genuine Bently Nevada modules.
