Product Overview
The Bently Nevada 3500/15 133300-01 is a Low Voltage DC Power Input Module designed for the 3500 series monitoring system. This module works with the Low Voltage DC Power Supply to convert incoming DC power into the regulated voltages required by the rack. Its robust design ensures reliable operation in demanding industrial environments.
Key Features & Benefits
-
Input Voltage Range: Accepts 20 to 30 Vdc, providing flexibility for various DC power sources.
-
Over-Voltage Protection: The internal fuse opens on over-voltage, safeguarding the module and the rest of the system.
-
Full Rack Current Draw: Supports up to 11.0 A maximum, powering fully loaded racks.
-
Supply OK LED: Front-panel indicator confirms power supply health at a glance.
-
Compact Design: Measures 120.7 mm x 25.4 mm x 114.3 mm (4.75 in x 1.0 in x 4.5 in) and weighs only 0.34 kg (0.75 lb).
-
Wide Temperature Range: Operates from -30 °C to +65 °C, suitable for harsh environments.
Technical Specifications
| Parameter |
Value |
| Input Voltage |
20 to 30 Vdc |
| Full Rack Current Draw |
11.0 A (maximum) |
| Dimensions (H x W x D) |
120.7 mm x 25.4 mm x 114.3 mm (4.75 in x 1.0 in x 4.5 in) |
| Weight |
0.34 kg (0.75 lb) |
| Operating Temperature |
-30 °C to +65 °C (-22 °F to +150 °F) |
| Storage Temperature |
-40 °C to +85 °C (-40 °F to +185 °F) |
| Humidity |
95%, non-condensing |
The 3500/15 133300-01 meets stringent compliance standards including FCC Part 15, EMC Directive 2014/30/EU (EN 61000-6-2, EN 61000-6-4), LV Directive 2014/35/EU (EN 61010-1), and RoHS Directive 2011/65/EU. It also holds hazardous area approvals: cNRTLus (Class I, Zone 2; Class I, Division 2) and ATEX/IECEx (II 3 G).
Installation & Setup
The power supply module occupies two half-height slots on the left side of the rack, while the Bently Nevada 3500/15 133300-01 mounts directly behind the associated power supply. No minimum rack load is required, simplifying setup. Ensure the input voltage stays within 20-30 Vdc to prevent fuse opening.
Maintenance & Reliability
Regularly inspect the front-panel Supply OK LED to confirm operational status. The module's robust design minimizes maintenance needs, but periodic checks of the fuse and connections are recommended. The wide operating temperature range and compliance with maritime standards (DNV GL, ABS) make it suitable for offshore and marine applications.
Compatibility & Integration
This Bently Nevada 3500/15 133300-01 is designed exclusively for the 3500 series rack, ensuring seamless integration with other 3500 modules. It supports redundant power supplies when both slots are populated. Use it with the corresponding Low Voltage DC Power Supply (not included) for complete functionality.
Selection Guide
Before purchasing, verify your rack's power requirements and ensure the 20-30 Vdc input matches your facility's DC supply. For reliable sourcing, consider PLC Source PRO as your trusted supplier of genuine industrial automation parts.
